Chip Monolithic Ceramic Capacitors
for Smoothing
e
g
e
s
Features
1. Heat generation is low at high frequency because of
low dielectric loss.
2. Compared with aluminum electrolytic capacitors,
capacitance can be lower to obtain the same
smoothing performance.
3. Ceramic capacitor has no polarity and ensures long
life time.
L
W
s
Applications
6
鈥?DC-DC converter
鈥?Noise elimination LCD bias circuit
(Use for only alumina, paper or glass epoxy board)
Rated Voltage
(Vdc)
6.3
6.3
6.3
6.3
10
50
50
100
Dimensions (mm)
Part Number
L
W
T
e min.
2.0
鹵0.1
1.25
鹵0.1
1.25
鹵0.1
0.2 to 0.7
GJ221B
3.2
鹵0.15
1.6
鹵0.15
1.15
鹵0.1
0.3 to 0.8
GJ231M
1.35
鹵0.15
GJ232N
3.2
鹵0.3
2.5
鹵0.2
1.6
鹵0.15
0.3
GJ232C
1.8
鹵0.2
GJ232R
1.8
鹵0.2
GJ243R
4.5
鹵0.4
3.2
鹵0.3
0.3
2.2
鹵0.3
GJ243X
g min.
0.7
1.5
1.0
2.0
Part Number
GJ221BF50J106ZD01
GJ231MF50J226ZD01
GJ232CF50J476ZD01
GJ243RF50J107ZD11
GJ232NF51A226ZD01
GJ232RF51H475ZD01
GJ243XF51H106ZD12
GJ232RF52A105ZD01
TC
Y5V
Y5V
Y5V
Y5V
Y5V
Y5V
Y5V
Y5V
Capacitance
(碌F)
10 +80.-20%
22 +80.-20%
47 +80.-20%
100 +80.-20%
22 +80.-20%
4.7 +80.-20%
10 +80.-20%
1 +80.-20%
Length L
(mm)
2.00
3.20
3.20
4.50
3.20
3.20
4.50
3.20
Width W
(mm)
1.25
1.60
2.50
3.20
2.50
2.50
3.20
2.50
Thickness T
(mm)
1.25
1.15
1.60
1.80
1.35
1.80
2.20
1.8
30
T
1
2
3
4
5
6
