Relays
Series GC
Force guided relay rated for 10A, 230/240 Vac, 300 Vdc
Available in 4, 6, 8 or 10 pole configuration. See Table 1 for part
numbers.
New Series GC
10A, 230/240VAC, 300VDC
SINGLE THROW FOUR/SIX/EIGHT/TEN POLE
ELECTRICAL SPECIFICATIONS
GENERAL SPECIFICATIONS
Parameter
Operate Time (See Note 1)
Release Time (See Note 1)
Switching Frequency
Shock (11 msec, See Note 3)
Vibration (10-100 Hz, See Note 3)
Electrical Life
Mechanical Life
Ambient Temperature
Min
Typ
30
7
Max Units
msec
msec
5
10
10
Hz
g
g
Cycles
Cycles
80
o
FEATURES:
鈥?Force Guided Contacts per EN50205:
Consists of at least one NO and one NC
contact mechanically linked. This allows
the contact鈥榮 behavior to be pre-
determined and the user the ability to
monitor the contact.The mechanism
provides true status.
鈥?Dielectric designed for 3-phase systems.
鈥?Contacts are physically linked making it
impossible for a NO and NC to be closed
simultaneously.
鈥?Internal creepage distances and
clearances are designed for Overvoltage
Category III and Degree of Pollution 2 per
IEC 60664.
鈥?Wide range of Contact configurations and
Coil Voltages.
10
5
10
7
-25
C
CONTACT SPECIFICATIONS
Maximum Load Current
2 Contacts
3 Contacts
4 Contacts
5 Contacts
6 Contacts
7 Contacts
8 Contacts
Maximum Switching Voltage
10
8.4
7.3
6.5
5.9
5.5
5.1
A
A
A
A
A
A
A
APPROVALS:
UL: Approved
TUV / CSA: Pending
ACCESSORIES:Contact Factory
Current regulator unit DIL housing
Current regulator unit SO.8 housing
Retaining clip
230/240 Vac
300
Vdc
Maximum Load Capacity (Resistive)
2000/120 VA/W
漏 2000 TELEDYNE RELAYS
800-284-7007 鈥?www.teledynerelays.com
GC 1
