GBU801 鈥?GBU807
Single Phase 8.0 AMPS. Glass Passivated
Bridge Rectifiers
GBU
Features
UL Recognized File # E-96005
Ideal for printed circuit board
Reliable low cost construction
Plastic material has Underwriters Laboratory
Flammability Classification 94V-0
High case dielectric strength of 1500VRMS
Surge overload rating to 200 amperes peak
High temperature soldering guaranteed:
o
260 C / 10 seconds / .375鈥? (9.5mm) lead
lengths.
.020R(TYP.)
.310(7.90)
.290(7.40)
.160(4.1)
.140(3.5)
.880(22.3)
.860(21.8)
0.125(3.2)x45
CHAMFER
.740(18.8)
.720(18.3)
.140(3.56)
.130(3.30)
9
TYP.
.085(2.16)
.065(1.65)
.075
(1.9)R
.080(2.03)
.060(1.52)
.100(2.54)
.085(2.16)
.050(1.27)
.040(1.02)
.190(4.83)
.210(5.33)
.710(18.0)
.690(17.5)
.085(2.16)
.075(1.90)
.080(2.03)
.065(1.65)
.022(0.56)
.018(0.46)
Mechanical Data
Case: Molded plastic body.
Terminals: Plated leads solderable per
MIL-STD-750, Method 2026.
Weight: 0. 3 ounce, 4.3 grams
Mounting torque: 5 in. lb. Max.
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
C
= 100
o
C
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 4.0A
@ 8.0A
Maximum DC Reverse Current @ T
A
=25 C
o
at Rated DC Blocking Voltage @ T
A
=125 C
Rating for fusing
( t<8.3ms )
( Note 1 )
( Note 2 )
o
Symbol GBU GBU GBU GBU GBU GBU GBU
Units
801 802 803 804 805 806 807
V
RRM
50
100 200 400 600 800 1000
V
V
RMS
35
70
140 280 420 560 700
V
V
DC
50
100 200 400 600 800 1000
V
I
(AV)
I
FSM
8.0
200
A
A
V
F
I
R
Typical Junction Capacitance ( Note 3 )
Typical Thermal Resistance Per Leg
I
2
t
Cj
R
胃JA
R
胃JC
T
J
1.0
1.1
5.0
500
166
211
21
2.0
-55 to +150
-55 to + 150
94
V
uA
uA
2
A sec
pF
o
C/W
o
o
Operating Temperature Range
Storage Temperature Range
T
STG
1. Units Mounted In Free Air No Heat Sink On PCB 0.5鈥?x 0.5 鈥?(12mm x 12mm) Copper Pads,
Notes
0.375鈥?(9.5mm) Lead Length.
2. Units Case Mounted On 4鈥?x 6鈥?x 0.25鈥?Al. Plate Heat Sink.
3. Measured at 1.0 MHZ and applied Reverse Voltage of 4.0V.
C
C
Version: A06
