Low Signal Relay
s
Fourth generation design
s
Design based on worldwide communica-
G6K
s
s
s
s
tions, computer peripheral and office
automation relay requirements
Offers excellent board space savings
Meets 2.5kV Bellcore surge require-
ments
Terminal design based on Omron's
successful G6S relay
Available in PCB through-hole, SMT
gullwing and SMT 鈥渋nside-L鈥?terminals
soon!
s
85擄C high ambient versions coming
Ordering Information
To Order: Select the part number and add the desired coil voltage rating (e.g., G6K-2F-DC5).
Part number
(non-latching, fully sealed)
Type
Standard
Contact form
DPDT
SMT gullwing
G6K-2F
To be announced
SMT 鈥渋nside-L鈥?/div>
G6K-2G
PCB through-hole
G6K-2P
High-Ambient DPDT
Specifications
s
CONTACT DATA
Load
Rated load
Contact material
Max. carry current
Max. operating voltage
Max. operating current
Max. switching capacity
Min. permissible load
Resistive load (cos蠁=1)
0.3 A at 125 VAC
1 A at 30 VDC
Ag (Au clad)
1A
125 VAC, 60 VDC
1A
37.5 VA, 30W
10
碌A(chǔ)
at 10 mVDC
