Low Signal Relay
s
High sensitivity 鈥?can be driven by digital
s
s
s
s
s
G6A
s
circuits
Low-profile design allows use in 12.70 mm
(0.50 in) PC board rack
Surge withstand voltage meets FCC Part 68
regulation
Units can be mounted side by side due to
low magnetic leakage
Special models available for ultrasonic
cleaning and low thermoelectromotive force
Unique moving loop (permanent magnet)
armature reduces relay size, magnetic
interference, and contact bounce time
Single or double coil winding types available
Ordering Information
To Order: Select the part number and add the desired coil voltage rating, (e.g., G6A-274P-ST-US-DC12).
s
NON-LATCHING
Type
Standard
High-sensitivity
Low-sensitivity
Contact form
DPDT
4PDT
DPDT
4PDT
DPDT
4PDT
Part number
AgPd (Au clad)
G6A-234P-ST-US
G6A-434P-ST-US
G6A-234P-ST15-US
G6A-434P-ST20-US
G6A-234P-ST40-US
G6A-434P-ST40-US
Ag (Au clad)
G6A-274P-ST-US
G6A-474P-ST-US
G6A-274P-ST15-US
G6A-474P-ST20-US
G6A-274P-ST40-US
G6A-474P-ST40-US
s
LATCHING
Single coil
Part number
AgPd (Au clad)
G6AU-234P-ST-US
G6AU-434P-ST-US
Type
Standard
Contact form
DPDT
4PDT
Ag (Au clad)
G6AU-274P-ST-US
G6AU-474P-ST-US
Dual coil
Part number
AgPd (Au clad)
G6AK-234P-ST-US
G6AK-434P-ST-US
G6AK-234P-ST40-US
G6AK-434P-ST40-US
Type
Standard
Low-sensitivity
Contact form
DPDT
4PDT
DPDT
4PDT
Ag (Au clad)
G6AK-274P-ST-US
G6AK-474P-ST-US
G6AK-274P-ST40-US
G6AK-474P-ST40-US
Note: Other options available for ST10 ultra high reliability, high temperature 85擄C (185擄F), ST1 reverse coil polarity, BS British
standard. Contact your OMRON sales representative for details.
