G4B-112T1-US Datasheet

  • G4B-112T1-US

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

General Purpose Relay
s
Miniature relay ideal for switching motor
G4B
load, lamp load, heater, etc.
s
Creepage distance of more than 2.03 mm
(0.08 in).
s
Upper mounting bracket type for easy
wiring and mounting
Ordering Information
To Order: Select the part number from the available types chart and add the desired coil voltage rating, (e.g., G4B-112T-US-DC6).
Type
Standard
Load contact terminal
Quick connect #250
Coil terminal
Quick connect #110
Quick connect #187
PC board
High capacity
PC board
Quick connect #187
Contact form
SPST-NO
SPDT
SPST-NO
SPDT
SPST-NO
SPDT
SPST-NO
SPDT
SPST-NO
SPDT
Part number
G4B-112T-US
G4B-112T-C-US
G4B-112T1-US
G4B-112T1-C-US
G4B-112TP-US
G4B-112TP-C-US
G4B-112TP-FD-US-RP
G4B-112TP-FD-C-US-RP
G4B-112T1-FD-US-RP
G4B-112T1-FD-C-US-RP
Note: 1. Class "B" insulation available. For information consult your OMRON representative.
2. High capacity types are also available with #110 connect coil terminals.
Specifications
s
CONTACT DATA
Type
Load
Rated load
Contact material
Carry current
Max. operating voltage
Max. operating current
Max. switching capacity
Min. permissible load
Standard
Resistive (p.f.=1)
220 VAC 15A
24 VDC 15A
AgCdO
20A
250 VAC, 125 VDC
20 A
3,300VA, 360W
100 mA, 5 VDC
Inductive (p.f.=0.40)
(L/R=7ms)
220 VAC 10A
24 VDC 7A
High capacity
Resistive (p.f.=1)
220 VAC 25A
24 VDC 25A
AgInSn
25A
250 VAC, 125 VDC
25A
5,500VA, 600W
Inductive (p.f.=0.40)
(L/R=7ms)
220 VAC 20A
24 VDC 15A
鈥?/div>
鈥?/div>
2,200VA, 170W
