FXL5T244 Low Voltage Dual Supply 5-Bit Signal Translator with Configurable Voltage Supplies and Signal Levels
and 3-STATE Outputs
June 2004
Revised June 2004
FXL5T244
Low Voltage Dual Supply 5-Bit Signal Translator
with Configurable Voltage Supplies
and Signal Levels and 3-STATE Outputs
General Description
The FXL5T244 is a configurable dual-voltage-supply trans-
lator designed for one-way (unidirectional) voltage transla-
tion of signals between two voltage levels. The device
allows translation between voltages as high as 3.6V to as
low as 1.1V. A Inputs and the OE Control Pin track the V
CCI
level, and Y Outputs track the V
CCO
level. Both inputs and
outputs are designed to accept supply voltage levels from
1.1V to 3.6V. This allows for unidirectional voltage transla-
tion over a variety of voltage levels: 1.2V, 1.5V, 1.8V, 2.5V,
and 3.3V.
The device remains in 3-STATE until both V
CC
s reach
active levels allowing either V
CC
to be powered-up first.
The device also contains power down control circuits that
place the device in 3-STATE if either V
CC
is removed. The
OE input, when HIGH, disables the outputs by placing
them in 3-STATE condition.
Features
s
One-way (unidirectional) translation between any
2 levels from 1.1V to 3.6V
s
Fully configurable, inputs and outputs track respective
V
CC
levels
s
Non-preferential power-up sequencing; either V
CC
may
be powered-up first
s
Outputs remain in 3-STATE until active V
CC
level is
reached
s
Outputs switch to 3-STATE if either V
CC
is at GND
s
Power-off protection
s
Control input (OE) level is referenced to V
CCI
voltage
s
Packaged in 14-terminal DQFN (2.5mm x 3.0mm)
package
s
ESD protection exceeds:
鈥?4kV HBM ESD
(per JESD22-A114 & Mil Std 883e 3015.7)
鈥?8kV HBM I/O to GND ESD
(per JESD22-A114 & Mil Std 883e 3015.7)
鈥?1kV CDM ESD (per ESD STM 5.3)
鈥?200V MM ESD (per JESD22-A115 & ESD STM5.2)
Ordering Code:
Order Number
FXL5T244BQX
Package
Number
MLP014A
Package Description
14-Terminal Depopulated Quad Very-Thin Flat Pack No Leads (DQFN), JEDEC MO-241,
2.5 x 3.0mm
漏 2004 Fairchild Semiconductor Corporation
DS500892
www.fairchildsemi.com

FXL5T244BQX 產品屬性

  • Logic Translator Solutions

  • 3,000

  • 集成電路 (IC)

  • 邏輯 - 變換器

  • -

  • 變換器，雙向，3 態

  • 5

  • 電壓

  • 電壓

  • -

  • 1

  • 5

  • 無/無

  • 3.5ns

  • 1.1 V ~ 3.6 V

  • -40°C ~ 85°C

  • 14-WFQFN 裸露焊盤

  • 14-DQFN

  • 帶卷 (TR)

  • FXL5T244BQXTRFXL5T244BQX_NLFXL5T244BQX_NLTRFXL5T244BQX_NLTR-ND
