Intel

廬

80200 Processor based on Intel

廬

XScale

鈩?/div>

Microarchitecture

Datasheet

Product Features

High Performance Processor based on

Intel

廬

XScale

鈩?/div>

Microarchitecture

鈥?7-8 stage Intel

廬

Superpipelined

Technology

鈥?32-Entry Instruction Memory

Management Unit

鈥?32-Entry Data Memory Management

Unit

鈥?32 KByte, 32-way Set Associative

Instruction Cache

鈥?32 KByte, 32-way Set Associative Data

Cache

鈥?2 KByte, 2-way Set Associative

Mini-Data Cache

鈥?128-Entry Branch Target Buffer

鈥?8-Entry Write Buffer

鈥?4-Entry Fill and Pend Buffers

Intel

廬

Dynamic Voltage Management

鈥?Core Voltage Range: 0.95 V to 1.55 V

鈥?Internal Clock Scalable by Software up

to 733 MHz

鈥?Input Clock: 33-66 MHz

ARM* Version 5TE Compliant

Application-Code Compatible with

Intel

廬

StrongARM* SA-110

Power Management

鈥?Core Power is ~500mW at 600MHz

鈥?Core Voltage Operation Down to 0.95 V

鈥?Idle and Sleep Modes

Intel

廬

Media Processing Technology

鈥?Multiply-Accumulate Coprocessor

High Performance External Bus

鈥?64- or 32-Bit Data Interface

鈥?Optional ECC Protection

鈥?Frequency up to 100 MHz

鈥?Asynchronous to Processor Clock

Performance Monitoring Unit

鈥?Two 32-Bit Event Counters

鈥?One 32-Bit Clock Counter

鈥?Monitors Occurrence and Duration

Events

Debug Unit

鈥?Accessible through JTAG Port

鈥?Hardware Breakpoints

鈥?256-Entry Trace Buffer

August 2002

Reference Number: 273414-004
