FM24C64V Datasheet

  • FM24C64V

  • 64K-Bit Standard 2-Wire Bus Interface Serial EEPROM

  • 13頁

  • FAIRCHILD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

FM24C64 鈥?64K-Bit Standard 2-Wire Bus Interface Serial EEPROM
December 2001
FM24C64 鈥?64K-Bit Standard 2-Wire Bus
Interface Serial EEPROM
General Description
FM24C64 is a 64Kbit CMOS non-volatile serial EEPROM orga-
nized as 8K x 8 bit memory. This device confirms to Extended IIC
2-wire protocol that allows accessing of memory in excess of
16Kbit on an IIC bus. This serial communication protocol uses a
Clock signal (SCL) and a Data signal (SDA) to synchronously
clock data between a master (e.g. a microcontroller) and a slave
(EEPROM). FM24C64 is designed to minimize pin count and
simplify PC board layout requirements.
FM24C64 offers hardware write protection where by the entire
memory array can be write protected by connecting WP pin to V
CC
.
This section of memory then becomes unalterable until the WP pin
is switched to V
SS
.
鈥淟Z鈥?and 鈥淟鈥?versions of FM24C64 offer very low standby current
making them suitable for low power applications. This device is
offered in SO, TSSOP and DIP packages.
Fairchild EEPROMs are designed and tested for applications
requiring high endurance, high reliability and low power consump-
tion.
Features
I
Extended operating voltage: 2.5V to 5.5V
I
Up to 400 KHz clock frequency at 2.5V to 5.5V
I
Low power consumption
鈥?0.5mA active current typical
鈥?10碌A(chǔ) standby current typical
鈥?1碌A(chǔ) standby current typical (L version)
鈥?0.1碌A(chǔ) standby current typical (LZ version)
I
Schmitt trigger inputs
I
32 byte page write mode
I
Self timed write cycle (6ms typical)
I
Hardware Write Protection for the entire array
I
Endurance: up to 100K data changes
I
Data Retention: Greater than 40 years
I
Packages: 8-Pin DIP, 8-Pin SO and 8-Pin TSSOP
I
Temperature range
鈥?Commercial: 0擄C to +70擄C
鈥?Industrial (E): -40擄C to +85擄C
鈥?Automotive (V): -40擄C to +125擄C
Block Diagram
VSS
VCC
WP
SDA
START
STOP
LOGIC
CONTROL
LOGIC
SLAVE ADDRESS
REGISTER &
COMPARATOR
E2PROM
ARRAY
WRITE
LOCKOUT
H.V. GENERATION
TIMING &CONTROL
SCL
XDEC
A2
A1
A0
WORD
ADDRESS
COUNTER
R/W
YDEC
CK
DIN
DATA REGISTER
DOUT
漏 2001 Fairchild Semiconductor Corporation
FM24C64 Rev. C
1
www.fairchildsemi.com
