FDC3601N Datasheet

  • FDC3601N

  • Dual N-Channel 100V Specified PowerTrench MOSFET

  • 93.85KB

  • 5頁

  • FAIRCHILD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

FDC3601N
August 2001
FDC3601N
Dual N-Channel 100V Specified PowerTrench
餂?/div>
MOSFET
General Description
These N-Channel 100V specified MOSFETs are
produced using Fairchild Semiconductor's advanced
PowerTrench process that has been especially tailored
to minimize on-state resistance and yet maintain low
gate charge for superior switching performance.
These devices have been designed to offer exceptional
power dissipation in a very small footprint for
applications where the bigger more expensive SO-8
and TSSOP-8 packages are impractical.
Applications
鈥?Load switch
鈥?Battery protection
鈥?Power management
Features
鈥?/div>
1.0 A, 100 V.
R
DS(ON)
= 500 m鈩?@ V
GS
= 10 V
R
DS(ON)
= 550 m鈩?@ V
GS
= 6.0 V
鈥?/div>
Low gate charge (3.7nC typical)
鈥?/div>
Fast switching speed.
鈥?/div>
High performance trench technology for extremely
low R
DS(ON)
.
鈥?/div>
SuperSOT
TM
-6 package: small footprint 72%
(smaller than standard SO-8); low profile (1mm thick).
D2
S1
D1
4
5
G2
3
2
1
SuperSOT
TM
-6
S2
G1
6
Absolute Maximum Ratings
Symbol
V
DSS
V
GSS
I
D
P
D
Drain-Source Voltage
Gate-Source Voltage
Drain Current
鈥?Continuous
鈥?Pulsed
T
A
=25 C unless otherwise noted
o
Parameter
Ratings
100
鹵20
(Note 1a)
Units
V
V
A
W
1.0
4.0
0.96
0.9
0.7
鈭?5
to +150
Power Dissipation for Single Operation
(Note 1a)
(Note 1b)
(Note 1c)
T
J
, T
STG
Operating and Storage Junction Temperature Range
擄C
Thermal Characteristics
R
胃JA
R
胃JC
Thermal Resistance, Junction-to-Ambient
Thermal Resistance, Junction-to-Case
(Note 1a)
(Note 1)
130
60
擄C/W
擄C/W
Package Marking and Ordering Information
Device Marking
.601
Device
FDC3601N
Reel Size
7鈥欌€?/div>
Tape width
8mm
Quantity
3000 units
餂?001
Fairchild Semiconductor Corporation
FDC3601N Rev C(W)

FDC3601N 產品屬性

  • High Voltage Switches for Power Processing

  • 3,000

  • 分離式半導體產品

  • FET - 陣列

  • PowerTrench®

  • 2 個 N 溝道（雙）

  • 邏輯電平門

  • 100V

  • 1A

  • 500 毫歐 @ 1A，10V

  • 4V @ 250µA

  • 5nC @ 10V

  • 153pF @ 50V

  • 700mW

  • 表面貼裝

  • SOT-23-6 細型，TSOT-23-6

  • 6-SSOT

  • 帶卷 (TR)

  • FDC3601N-NDFDC3601NTR
