FAN1112 Datasheet

  • FAN1112

  • 1A 1.2V Low Dropout Linear Regulator

  • 8頁

  • FAIRCHILD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

www.fairchildsemi.com
FAN1112
1A 1.2V Low Dropout Linear Regulator
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Low dropout voltage
Load regulation: 0.05% typical
Trimmed current limit
On-chip thermal limiting
Standard SOT-223 and TO-252 packages
Three-terminal 鏗亁ed 1.2V
Description
The FAN1112 is a 1.2V low dropout three-terminal
regulator with 1A output current capability. The device has
been optimized for low voltage where transient response and
minimum input voltage are critical.
Current limit is trimmed to ensure speci鏗乪d output current
and controlled short-circuit current. On-chip thermal limiting
provides protection against any combination of overload and
ambient temperatures that would create excessive junction
temperatures.
Unlike PNP type regulators where up to 10% of the output
current is wasted as quiescent current, the quiescent current
of the FAN1112 鏗俹ws into the load, increasing ef鏗乧iency.
The FAN1112 regulator is available in the industry-standard
SOT-223 and TO-252 (DPAK) power packages.
Applications
鈥?Post regulator for switching supplies
鈥?Supply for low-voltage processors
Typical Application
FAN1112
V
IN
= 3.3V
10碌F
GND
+
V
IN
V
OUT
+
22碌F
1.2V at 1A
REV. 1.0.1 9/27/01
