廬

DTVseries

(CRT HORIZONTAL DEFLECTION)

HIGH VOLTAGE DAMPER DIODE

MAIN PRODUCTS CHARACTERISTICS

I

F(AV)

V

RRM

V

F

5 A to 10 A

1500 V

1.3 V to 1.5 V

A

A

K

K

FEATURES AND BENEFITS

HIGH BREAKDOWN VOLTAGE CAPABILITY

VERY FAST RECOVERY DIODE

SPECIFIED TURN ON SWITCHING

CHARACTERISTICS

LOW STATIC AND PEAK FORWARD VOLTAGE

DROP FOR LOW DISSIPATION

SUITED TO 32-110kHz MONITORS AND

16kHz TV DEFLECTION

INSULATED VERSION (ISOWATT220AC):

Insulating voltage = 2000V DC

Capacitance = 12pF

PLANAR TECHNOLOGY ALLOWING HIGH

QUALITY

AND

BEST

ELECTRICAL

CHARACTERISTICS

ABSOLUTE RATINGS

Symbol

V

RRM

I

F(RMS)

I

FSM

RMS forward current

Surge non repetitive forward current

tp = 10ms half sine wave

DTV16

DTV32

DTV56

DTV64

DTV82

DTV110

T

stg

T

j

Storage temperature range

Maximum operating junction temperature

Parameter

Repetitive peak reverse voltage

Value

1500

15

50

75

80

80

80

80

-65 to 150

150

擄C

擄C

1/10

TO-220AC

DTVxxxD

ISOWATT220AC

DTVxxxF

DESCRIPTION

High voltage diode with high current capability

dedicated to horizontal deflection. DTV16 is

optimized to TV meanwhile DTV32 to DTV110 are

covering the full range of monitors from the low

end to the professional hi-definition SXGA CAD

display units.

These devices are packaged either in TO220-AC

or in ISOWATT220AC.

Unit

V

A

A

August 1999 - Ed: 2B
