DS8925 LocalTalk Dual Driver/Triple Receiver

December 1998

DS8925

LocalTalk

鈩?/div>

Dual Driver/Triple Receiver

General Description

The DS8925 is a dual driver/triple receiver device optimized

to provide a single chip solution for a LocalTalk Interface.

The device provides one differential TIA/EIA-422 driver, one

TIA/EIA-423 single ended driver, one TIA/EIA-422 receiver

and two TIA/EIA-423 receivers, all in a surface mount 16 pin

package. This device is electrically similar to the 26LS30 and

26LS32 devices.

The drivers feature

鹵

10V common mode range, and the dif-

ferential driver provides TRI-STATEable outputs. The receiv-

ers offer

鹵

200 mV thresholds over the

鹵

10V common mode

range.

Features

Single chip solution for LocalTalk port

Two driver/three receivers per package

Wide common mode range:

鹵

10V

鹵

200 mV receiver sensitivity

70 mV typical receiver input hysteresis

Available in SOIC packaging

Connection Diagram

Dual-In-Line Package

Functional Diagram

DS011895-1

Order Number DS8925M

See NS Package Number M16A

DS011895-2

TRI-STATE

廬

is a registered trademark of National Semiconductor Corporation.

LocalTalk

鈩?/div>

is a trademark of Apple Computer Incorporated.

漏 1998 National Semiconductor Corporation

DS011895

www.national.com
