Preliminary Speci鏗乧ations
Low Cost Six-Way Power Splitter/Combiner
2200 - 2500 MHz
DS56-0004
V1.A
Features
q
q
q
q
q
q
SOW-16
Pin 16
Small Size and Low Pro鏗乴e
Industry Standard SOW-16 SMT Plastic Package
Superior Repeatability
Insertion Loss: 1.1 dB Typical
Isolation: 22 dB Typical
Low Cost
Orientation
Mark
Pin 1
.2914-.2992
.394-.419
(7.40-7.60)
(10.00-10.65)
-B-
.010(0.25) M B M
Description
M/A-COM鈥檚 DS56-0004 is an IC-based monolithic power
splitter/combiner in a low cost SOW 16-lead plastic
package. This 6-way power splitter/combiner is ideally
suited for applications where small size, low profile
and low cost, without sacrificing performance, are
required. Typical applications include base stations,
portables and PCMCIA cards for wireless data, spread
spectrum and some satellite systems. Available in tape
and reel.
The DS56-0004 is fabricated using a passive-integrated
circuit process. The process features full chip
passivation for increased performance and reliability.
.004 (0.10)
0.050(1.27) BSC.
.3977-.4133
(10.10-10.50)
-A-
.0926-.1043
(7.40-7.60)
0擄-8擄
-C-
.0040-.0118
(0.10-0.30)
.010-.029 x
45擄 Chamfer
(0.25-0.75)
.016-.050
(0.40-1.27)
.0091-.0125
(0.23-0.32)
.013-.020 TYP
(0.33-0.51)
.010(0.25) M C A M B S
16-Lead SOP outline dimensions
Wide body (.300)
(All dimensions per JEDEC No. MS-013-AA, Issue C)
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx =
鹵
0.010 (.xx =
鹵
0.25)
.xx =
鹵
0.02 (.x =
鹵
0.5)
Ordering Information
Part Number
DS56-0004
DS56-0004-TR
DS56-0004-RTR
Package
SOW 16-Lead Plastic Package
Forward Tape & Reel*
Reverse Tape & Reel*
*
If speci鏗乧 reel size is required, consult factory for part number
assignment.
Typical Electrical Speci鏗乧ations
1
,
TA = +25擄C
Parameter
Units
Min.
Typ.
Max.
Insertion Loss
Isolation
VSWR
Amplitude Balance
Phase Balance
dB
dB
dB
擄
18
1.2
22
1.5:1
0.8
10擄
1.5
1.8:1
1.2
18擄
1. All speci鏗乧ations apply with a 50-ohm source and load impedance.
This Preliminary Speci鏗乧ations Data Sheet Sheet Contains Typical Electrical Speci鏗乧ations Which May Change Prior to Final Introduction.
