Low Cost Four-Way SMT Power Splitter/Combiner
2200 - 2500 MHz
DS54-0004
V4.00
Features
q
q
q
q
q
q
q
SOW-16
Pin 16
Small Size and Low Pro鏗乴e
Industry Standard SOW-16 SMT Plastic Package
Superior Repeatability
Insertion Loss: 1.0 dB Typical
Isolation: 21 dB Typical
Amplitude Balance: 0.2 dB Typical
Low Cost
Orientation
Mark
Pin 1
.2914-.2992
.394-.419
(7.40-7.60)
(10.00-10.65)
-B-
.010(0.25) M B M
Description
M/A-COM鈥檚 DS54-0004 is an IC-based monolithic power
splitter/combiner in a low cost SOW 16-lead plastic
package. This four-way power splitter/combiner is ide-
ally suited for applications where small size, low pro鏗乴e
and low cost, without sacrificing performance, are
required. Typical applications include base stations,
portables and PCMCIA cards for wireless data
LAN/WAN and other applications using the 2200-2500
MHz frequency range. Available in tape and reel.
The DS54-0004 is fabricated using a passive-integrated
circuit process. The process features full chip passiva-
tion for increased performance and reliability.
.004 (0.10)
0.050(1.27) BSC.
.3977-.4133
(10.10-10.50)
-A-
.0926-.1043
(7.40-7.60)
0擄-8擄
-C-
.010-.029 x
45擄 Chamfer
(0.25-0.75)
.0040-.0118
.013-.020 TYP
(0.10-0.30)
(0.33-0.51)
.010(0.25) M C A M B S
.016-.050
(0.40-1.27)
.0091-.0125
(0.23-0.32)
16-Lead SOP outline dimensions
Wide body (.300)
(All dimensions per JEDEC No. MS-013-AA, Issue C)
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵 0.010 (.xx = 鹵 0.25)
.xx = 鹵 0.02 (.x = 鹵 0.5)
Ordering Information
Part Number
DS54-0004
DS54-0004-TR
DS54-0004-RTR
assignment.
Package
SOW 16-Lead Plastic Package
Forward Tape & Reel*
Reverse Tape & Reel*
*
If speci鏗乧 reel size is required, consult factory for part number
Typical Electrical Speci鏗乧ations
1
,
T
A
= +25擄C
Parameter
Insertion Loss Above 6.0 dB
Isolation
VSWR Input
Output
Amplitude Balance
Phase Balance
Units
dB
dB
Min.
15
Typ.
1.0
21
1.5:1
1.4:1
0.2
2
Max.
1.2
1.9:1
1.7:1
0.5
5
dB
擄
1. All speci鏗乧ations apply with a 50-ohm source and load impedance.
Speci鏗乧ations Subject to Change Without Notice.
