Low Cost Four-Way SMT Power Splitter/Combiner
1200 - 1660 MHz
DS54-0003
V4.00
Features
q
q
q
q
q
q
q
q
SOW-16
Pin 16
Low Cost
Small Size and Low Pro鏗乴e
Industry Standard SOW-16 SMT Plastic Package
Excellent Repeatability (Lot-to-Lot Variation)
Typical Isolation: 23 dB
Typical Amplitude Balance: 0.3 dB
Typical Insertion Loss: 1.0 dB
Commercial and Military GPS and LEO Frequency
Coverage
Orientation
Mark
Pin 1
.2914-.2992
.394-.419
(7.40-7.60)
(10.00-10.65)
-B-
.010(0.25) M B M
.3977-.4133
(10.10-10.50)
-A-
.004 (0.10)
0.050(1.27) BSC.
.0926-.1043
(7.40-7.60)
0擄-8擄
-C-
.0040-.0118
(0.10-0.30)
.010-.029 x
45擄 Chamfer
(0.25-0.75)
.016-.050
(0.40-1.27)
.0091-.0125
(0.23-0.32)
Description
M/A-COM鈥檚 DS54-0003 is an IC based monolithic power
splitter/combiner in a low cost SOW-16 plastic package.
This device is ideally suited for applications where PCB
real estate is at a premium and standard packaging for
automated assembly and low cost are critical. Typical
applications include infrastructure, portables and periph-
eral devices (PCMCIA cards) for commercial and military
GPS plus LEO applications. Available in tape and reel.
The DS54-0003 is fabricated using a passive-integrated
circuit process. The process features full chip passivation
for increased performance and reliability.
.013-.020 TYP
(0.33-0.51)
.010(0.25) M C A M B S
16-Lead SOP outline dimensions
Wide body (.300)
(All dimensions per JEDEC No. MS-013-AA, Issue C)
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵 0.010 (.xx = 鹵 0.25)
.xx = 鹵 0.02 (.x = 鹵 0.5)
Ordering Information
Part Number
DS54-0003
DS54-0003-TR
DS54-0003-RTR
Package
SOW-16 Lead Plastic Package
Forward Tape and Reel
*
Reverse Tape and Reel
*
* If speci鏗乧 reel size is required, consult factory for part number
assignment.
Electrical Speci鏗乧ations
1
,
T
A
= +25擄C
Parameter
Insertion Loss Above 6.0 dB
Isolation
1200-1430 MHz
1430-1660 MHz
VSWR
Input
Output
Amplitude Balance
Phase Balance
dB
擄
Units
dB
dB
dB
13
18
Min.
Typ.
1.0
18
23
1.2:1
1.4:1
0.3
2
1.4:1
1.7:1
0.6
5擄
Max.
1.2
1. All speci鏗乧ations apply with a 50-ohm source and load impedance.
Speci鏗乧ations Subject to Change Without Notice.
