Preliminary Speci鏗乧ations
Low-Cost Three-Way Power Splitter/Combiner
1510 - 1660 MHz
DS53-0002
V1.00
Features
q
q
q
q
q
q
SO-8
PIN 8
.1497-.1574
(3.80-4.00)
-B-
.2284-.2440
(5.80-6.20)
.010(0.25) M B M
Small Size and Low Pro鏗乴e
Industry Standard SOIC-8 SMT Plastic Package
Superior Repeatability
Excellent Insertion Loss 0.6 dB Typical
Low Cost
Frequency coverage for GPS and LEOS Programs
Orientation
mark
PIN 1
.1890-.1968
(4.80-5.00)
-A-
.004 (0.10)
Description
M/A-COM鈥檚 DS53-0002 is an IC based monolithic power
splitter in a low cost SOIC-8 plastic package. This 3-way
power splitter is ideally suited for applications where
small size, low pro鏗乴e and low cost, without sacri鏗乧ing
performance are required. Typical applications include
base stations, portables and PCMCIA cards for cellular
applications. Available in tape and reel.
The DS53-0002 is fabricated using a passive integrated
circuit process. The process features full chip passivation
for increased performance and reliability.
.0532-.0688
(1.35-1.75)
0擄-8擄
-C-
.0040-.0098
(0.10-0.25)
.013-.020 TYP.
(0.33-0.51)
.0099-0.0196
x 45擄 Chamfer
(0.25-0.50)
.016-.050
(0.40-1.27)
.0075-0.0098
(0.19-0.25)
.050(1.27) BSC.
.010(0.25) M C A M B S
8- Lead SOP outline dimensions
Narrow body .150
(All dimensions per JEDEC No. MS-012-AA, Issue C)
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵 0.010 (.xx = 鹵 0.25)
.xx = 鹵 0.02 (.x = 鹵0.5)
Ordering Information
Part Number
DS53-0002
DS53-0002-TR
DS53-0002-RTR
Description
SOIC 8-Lead Plastic Package
Forward Tape & Reel*
Reverse Tape & Reel*
*If speci鏗乧 reel size is required, consult factory for part number
assignment.
Typical Electrical Speci鏗乧ations
1
,
T
A
= +25擄C
Parameter
Insertion Loss above 4.78 dB
Isolation
VSWR
Amplitude Balance
Phase Balance
Unit
dB
dB
鈥?/div>
dB
擄
Min.
鈥?/div>
15
鈥?/div>
鈥?/div>
鈥?/div>
Typ.
0.6
18
1.4:1
0.4
6擄
Max.
0.7
鈥?/div>
1.6:1
0.6
10擄
1. All speci鏗乧ations apply with a 50 ohm source and load impedance.
The Preliminary Speci鏗乧ations Data Sheet Contains Typical Electrical Speci鏗乧ations Which May Change Prior to Final Introduction.
M/A-COM, Inc.
North America:
Tel. (800) 366-2266
Fax (800) 618-8883
s
1
Asia/Paci鏗乧: Tel. +81 3 3263 8761
Fax +81 3 3263 8769
s
Europe: Tel. +44 (1344) 869 595
Fax +44 (1344) 300 020
