DS2406/TR Datasheet

  • DS2406/TR

  • Peripheral IC

  • 277.70KB

  • 31頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DS2406
Dual Addressable Switch
Plus 1kbit Memory
www.maxim-ic.com
FEATURES
摟
摟
摟
摟
摟
摟
摟
摟
Open drain PIO pins are controlled and their
logic level can be determined over 1-Wire
廬
bus for closed-loop control
Replaces and is fully compatible with
DS2407 but no user-programmable power-on
settings and no Hidden Mode
PIO channel A sink capability of 50mA at
0.4V with soft turn-on; channel B 8mA at
0.4V
Maximum operating voltage of 13V at
PIO-A, 6.5V at PIO-B
1024 bits user-programmable OTP EPROM
User-programmable status memory to
control the device
Multiple DS2406鈥檚 can be identified on a
common 1-Wire bus and be turned on or off
independently of other devices on the bus
Unique, factory-lasered and tested 64-bit
registration number (8-bit family code +
48-bit serial number + 8-bit CRC tester)
assures error-free selection and absolute
identity because no two parts are alike
On-chip CRC16 generator allows detection
of data transfer errors
Built-in multidrop controller ensures
compatibility with other 1-Wire net products
Reduces control, address, data, programming
and power to a single data pin
Directly connects to a single port pin of a
microprocessor and communicates at up to
16.3 kbits/s
Supports Conditional Search with user-
selectable condition
V
cc
bondout for optional external supply to
the device (TSOC package only)
1-Wire communication operates over a wide
voltage range of 2.8V to 6.0V from -40擄C to
+85擄C
Low cost TO-92 or 6-pin TSOC surface
mount package
1 of 31
PIN ASSIGNMENT
TO-92
DALLAS
DS2406
6-PIN TSOC PACKAGE
1
2
3
TOP VIEW
6
5
4
SIDE VIEW
1
1
2
2
3
3
See Mech. Drawings
Section
BOTTOM VIEW
PIN DESCRIPTION
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
TO-92
Ground
Data
PIO-A
---
---
---
TSOC/CSP
Ground
Data
PIO-A
V
cc
NC
PIO-B
摟
摟
摟
摟
摟
摟
摟
摟
ORDERING INFORMATION
DS2406
DS2406P
DS2406/T&R
DS2406P/T&R
DS2406X
TO-92 package
6-pin TSOC package
Tape & Reel of DS2406
Tape & Reel of DS2406P
Chip Scale Pkg., Tape &
Reel
110501
