DP84T22-25 Datasheet

  • DP84T22-25

  • microCMOS Programmable 256k/1M/4M Dynamic RAM Controller/Dri...

  • 60頁

  • NSC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DP8420V 21V 22V-33 DP84T22-25 microCMOS Programmable
256k 1M 4M Dynamic RAM Controller Drivers
May 1992
DP8420V 21V 22V-33 DP84T22-25 microCMOS
Programmable 256k 1M 4M Dynamic RAM
Controller Drivers
General Description
The DP8420V 21V 22V-33 DP84T22-25 dynamic RAM
controllers provide a low cost single chip interface between
dynamic RAM and all 8- 16- and 32-bit systems The
DP8420V 21V 22V-33 DP84T22-25 generate all the re-
quired access control signal timing for DRAMs An on-chip
refresh request clock is used to automatically refresh the
DRAM array Refreshes and accesses are arbitrated on
chip If necessary a WAIT or DTACK output inserts wait
states into system access cycles including burst mode ac-
cesses RAS low time during refreshes and RAS precharge
time after refreshes and back to back accesses are guaran-
teed through the insertion of wait states Separate on-chip
precharge counters for each RAS output can be used for
memory interleaving to avoid delayed back to back access-
es because of precharge An additional feature of the
DP8422V DP84T22 is two access ports to simplify dual ac-
cessing Arbitration among these ports and refresh is done
on chip To make board level circuit testing easier the
DP84T22 incorporates TRI-STATE output buffers
Control
DP8420V
DP8421V
DP8422V
DP84T22
of Pins
(PLCC)
68
68
84
84
of Address
Outputs
9
10
11
11
Features
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
On chip high precision delay line to guarantee critical
DRAM access timing parameters
microCMOS process for low power
High capacitance drivers for RAS CAS WE and DRAM
address on chip
On chip support for nibble page and static column
DRAMs
TRI-STATE outputs (DP84T22 only)
Byte enable signals on chip allow byte writing in a word
size up to 32 bits with no external logic
Selection of controller speeds 25 MHz and 33 MHz
On board Port A Port B (DP8422V DP84T22 only) re-
fresh arbitration logic
Direct interface to all major microprocessors (applica-
tion notes available)
4 RAS and 4 CAS drivers (the RAS and CAS configura-
tion is programmable)
Largest
DRAM
Possible
256 kbit
1 Mbit
4 Mbit
4 Mbit
Direct Drive
Memory
Capacity
4 Mbytes
16 Mbytes
64 Mbytes
64 Mbytes
Access
Ports
Available
Single Access Port
Single Access Port
Dual Access Ports (A and B)
Dual Access and TRI-STATE
Block Diagram
DP8420V 21V 22V DP74T22 DRAM Controller
TL F 11109 鈥?1
FIGURE 1
TRI-STATE is a registered trademark of National Semiconductor Corporation
Staggered Refresh
TM
is a trademark of National Semiconductor Corporation
C
1995 National Semiconductor Corporation
TL F 11109
RRD-B30M105 Printed in U S A
