DG2303DL Datasheet

  • DG2303DL

  • High-Speed, Low rON, 1.8-V/2.5-V/3.3-V/5-V, SPST Analog Swit...

  • 5頁

  • VISHAY   VISHAY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DG2303
New Product
Vishay Siliconix
High-Speed, Low r
ON
, 1.8-V/2.5-V/3.3-V/5-V, SPST Analog Switch
(1-Bit Bus Switch)
FEATURES
D
D
D
D
D
D
SC-70 5-Lead Package
5-W Switch Connection Between Two Ports
Minimal Propagation Delay Through The Switch
Low I
CC
Zero Bounce In Flow-Through Mode
Control Inputs Compatible with TTL Level
DESCRIPTION
The DG2303 is a high-speed, 1-bit, low power,
TTL-compatible bus switch.
Using sub-micron CMOS
technology, DG2303 achieves low on-resistance and
negligible propagation delay.
The DG2303 consist of a bi-directional input/output pins A
and B. When the output enable (OE) is low, the input/output
pins are connected. When the OE is high, the switch is open
and a high-impedance state exists between input/output pins
A and B.
FUNCTIONAL BLOCK DIAGRAM AND PIN CONFIGURATION
TRUTH TABLE
SC-70
A
B
GND
1
2
3
Top View
Device Marking: E6
4
OE
5
V+
OE
L
H
B
HiZ State
A
Function
Disconnect
Connect
ORDERING INFORMATION
Temp Range
-40 to 85擄C
Package
SC70-5
Part Number
DG2303DL
Document Number: 72073
S-03422鈥擱ev. A, 03-Mar-03
www.vishay.com
1
