DDTC
(R1鹿R2 SERIES)
UA
NPN PRE-BIASED SMALL SIGNAL SOT-323
SURFACE MOUNT TRANSISTOR
Features
NEW PRODUCT
路
路
路
路
路
路
路
路
路
路
路
Epitaxial Planar Die Construction
Complementary PNP Types Available
(DDTA)
Built-In Biasing Resistors, R1鹿R2
Case: SOT-323, Molded Plastic
Case material - UL Flammability Rating 94V-0
Moisture sensitivity: Level 1 per J-STD-020A
Terminals: Solderable per MIL-STD-202,
Method 208
Terminal Connections: See Diagram
Marking: Date Code and Marking Code
(See Diagrams & Page 2)
Weight: 0.006 grams (approx.)
Ordering Information (See Page 2)
IN
P/N
DDTC113ZUA
DDTC123YUA
DDTC123JUA
DDTC143XUA
DDTC143FUA
DDTC143ZUA
DDTC114YUA
DDTC114WUA
DDTC124XUA
DDTC144VUA
DDTC144WUA
R1
(NOM)
1KW
2.2KW
2.2KW
4.7KW
4.7KW
4.7KW
10KW
10KW
22KW
47KW
47KW
R2
(NOM)
10KW
10KW
47KW
10KW
22KW
47KW
47KW
4.7KW
47KW
10KW
22KW
MARKING
N02
N05
N06
N09
N10
N11
N14
N15
N18
N21
N22
IN
A
OUT
B C
SOT-323
Dim
A
GND
Min
0.25
1.15
2.00
0.30
1.20
1.80
0.0
0.90
0.25
0.10
0擄
Max
0.40
1.35
2.20
0.40
1.40
2.20
0.10
1.00
0.40
0.18
8擄
Mechanical Data
G
H
K
B
C
D
M
0.65 Nominal
E
G
H
J
J
D
F
L
R
1
R
2
OUT
K
L
M
a
GND
All Dimensions in mm
IN
GND
SCHEMATIC DIAGRAM
OUT
Maximum Ratings
Supply Voltage, (3) to (1)
Input Voltage, (2) to (1)
@ T
A
= 25擄C unless otherwise specified
Symbol
V
CC
DDTC113ZUA
DDTC123YUA
DDTC123JUA
DDTC143XUA
DDTC143FUA
DDTC143ZUA
DDTC114YUA
DDTC114WUA
DDTC124XUA
DDTC144VUA
DDTC144WUA
DDTC113ZUA
DDTC123YUA
DDTC123JUA
DDTC143XUA
DDTC143FUA
DDTC143ZUA
DDTC114YUA
DDTC114WUA
DDTC124XUA
DDTC144VUA
DDTC144WUA
All
Value
50
-5 to +10
-5 to +12
-5 to +12
-7 to +20
-6 to +30
-5 to +30
-6 to +40
-10 to +30
-10 to +40
-15 to +40
-10 to +40
100
100
100
100
100
100
70
100
50
30
30
100
200
625
-55 to +150
Unit
V
Characteristic
V
IN
V
Output Current
I
O
mA
Output Current
Power Dissipation
Thermal Resistance, Junction to Ambient Air (Note 1)
Operating and Storage and Temperature Range
Note:
I
C
(Max)
P
d
R
qJA
T
j
, T
STG
mA
mW
擄C/W
擄C
1. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
DS30322 Rev. 3 - 2
1 of 4
DDTC (R1鹿R2 SERIES) UA
