DCR1574SY

DCR1574SY

Phase Control Thyristor

Replaces January 2000 version, DS4400-3.0

DS4400-4.0 July 2001

FEATURES

s

s

s

s

KEY PARAMETERS

V

DRM

I

T(AV)

I

TSM

dVdt

dI/dt

2800V

3419A

54500A

1000V/

碌

s

300A/

碌

s

Double Side Cooling.

High Surge Capability.

High Current.

Fatigue Free.

APPLICATIONS

s

s

s

High Power Drives.

High Voltage Power Supplies.

DC Motor Control.

VOLTAGE RATINGS

Type Number

Repetitive Peak

Voltages

V

DRM

V

RRM

V

2800

2700

2600

2500

2400

Conditions

DCR1574SY28

DCR1574SY27

DCR1574SY26

DCR1574SY25

DCR1574SY24

T

vj

= 0藲 to 125藲C,

I

DRM

= I

RRM

= 300mA,

V

DRM

, V

RRM

t

p

= 10ms,

V

DSM

& V

RSM

=

V

DRM

& V

RRM

+ 100V

respectively

Outline type code: Y

See Package Details for further information.

(The DCR1574 is also available in a thin package, type code V.

Please contact Customer Services for more information).

Lower voltage grades available.

ORDERING INFORMATION

When ordering, select the required part number shown in the

Voltage Ratings selection table.

For example:

DCR1574SY25

Note: Please use the complete part number when ordering

and quote this number in any future correspondance relating

to your order.

Fig. 1 Package outline

1/10

www.dynexsemi.com
