DCR1279SD

DCR1279SD

Phase Control Thyristor

Advance Information

Replaces March 1998 version, DS4643-3.2

DS4643-4.0 January 2000

APPLICATIONS

s

High Power Drives

s

High Voltage Power Supplies

s

DC Motor Control

KEY PARAMETERS

V

DRM

4800V

I

T(AV)

1088A

I

TSM

15000A

dVdt*

300V/

碌

s

dI/dt

200A/

碌

s

*Higher dV/dt selections available

FEATURES

s

Double Side Cooling

s

High Surge Capability

s

High Mean Current

s

Fatigue Free

VOLTAGE RATINGS

Type Number

Repetitive Peak

Voltages

V

DRM

V

RRM

V

4800

4700

4600

4500

4400

Conditions

DCR1279SD48

DCR1279SD47

DCR1279SD46

DCR1279SD45

DCR1279SD44

T

vj

= 0藲 to 125藲C,

I

DRM

= I

RRM

= 150mA,

V

DRM

, V

RRM

t

p

= 10ms,

V

DSM

& V

RSM

=

V

DRM

& V

RRM

+ 100V

respectively

Outline type code: D.

See package outline for further information.

Lower voltage grades available.

CURRENT RATINGS

T

case

= 60藲C unless stated otherwise.

Symbol

Double Side Cooled

I

T(AV)

I

T(RMS)

I

T

Mean on-state current

RMS value

Continuous (direct) on-state current

Half wave resistive load,

-

-

1088

1709

1574

A

A

A

Parameter

Conditions

Max.

Units

Single Side Cooled (Anode side)

I

T(AV)

I

T(RMS)

I

T

Mean on-state current

RMS value

Continuous (direct) on-state current

Half wave resistive load

-

-

762

1197

1034

A

A

A

1/9
