CYIS1SM1000AA-HQC Datasheet

  • CYIS1SM1000AA-HQC

  • 1M Pixel Radiation Hard CMOS Image Sensor

  • 630.77KB

  • 21頁

  • CYPRESS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

STAR1000
STAR1000 1M Pixel Radiation Hard
CMOS Image Sensor
Key Features
The STAR1000 sensor has the following characteristics:
鈥?Integrating 3-transistor Active Pixel Sensor.
鈥?1024 by 1024 pixels on 15
碌m
pitch.
鈥?Radiation tolerant design.
鈥?On-chip double sampling circuit to cancel Fixed Pattern
Noise.
鈥?Electronic shutter.
鈥?Read out rate: up to 11 full frames per second.
鈥?Region Of Interest (ROI) windowing.
鈥?On-chip 10-bit ADC.
鈥?Programmable gain amplifier.
鈥?Ceramic JLCC-84 package.
鈥?Available with BK7G18 glass and with N
2
filled cavity.
Sensor Description
The STAR1000 is a CMOS image sensor with 1024 by 1024
pixels on a 15 mm pitch. It features on-chip Fixed Pattern
Noise (FPN) correction, a programmable gain amplifier, and a
10-bit Analog-to-Digital Converter (ADC).
All circuits are designed using the radiation tolerant design
rules for CMOS image sensors, to allow a high tolerance
against total dose effects.
Registers that are directly accessed by the external controller
contain the X- and Y- addresses of the pixels to be read. This
architecture provides flexible operation and allows different
operation modes such as (multiple) windowing, subsampling,
etc.
Two versions od sensors are available: STAR1000 and
STAR1000BK7. The STAR1000 has a quartz glass lid and the
cavity between the die and the lid is filled with air. The
STAR1000BK7 has a BK7G18 glass lid and the cavity is filled
with N
2
which increases the temperature operating range.
Cypress Semiconductor Corporation
Document Number: 38-05714 Rev. *B
鈥?/div>
198 Champion Court
鈥?/div>
San Jose
,
CA 95134-1709
鈥?/div>
408-943-2600
Revised January 5, 2007
[+] Feedback

CYIS1SM1000AA-HQC 產品屬性

  • Cypress Semiconductor

  • 圖像傳感器和彩色傳感器

  • Image Sensors

  • 5 V

  • JLCC

  • 1024 H x 1024 V

  • Monochrome

  • + 60 C

  • 0 C

  • 1
