049V33
CY7C1049V33
512K x 8 Static RAM
Features
鈥?High speed
鈥?t
AA
= 15 ns
鈥?Low active power
鈥?504 mW (max.)
鈥?Low CMOS standby power (Commercial L version)
鈥?1.8 mW (max.)
鈥?2.0V Data Retention (660
碌W
at 2.0V retention)
鈥?Automatic power-down when deselected
鈥?TTL-compatible inputs and outputs
鈥?Easy memory expansion with CE and OE features
sion is provided by an active LOW Chip Enable (CE), an active
LOW Output Enable (OE), and three-state drivers. Writing to
the device is accomplished by taking Chip Enable (CE) and
Write Enable (WE) inputs LOW. Data on the eight I/O pins
(I/O
0
through I/O
7
) is then written into the location specified on
the address pins (A
0
through A
18
).
Reading from the device is accomplished by taking Chip
Enable (CE) and Output Enable (OE) LOW while forcing Write
Enable (WE) HIGH. Under these conditions, the contents of
the memory location specified by the address pins will appear
on the I/O pins.
The eight input/output pins (I/O
0
through I/O
7
) are placed in a
high-impedance state when the device is deselected (CE
HIGH), the outputs are disabled (OE HIGH), or during a write
operation (CE LOW, and WE LOW).
The CY7C1049V33 is available in a standard 400-mil-wide
36-pin SOJ package with center power and ground (revolu-
tionary) pinout.
Functional Description
The CY7C1049V33 is a high-performance CMOS Static RAM
organized as 524,288 words by 8 bits. Easy memory expan-
Logic Block Diagram
Pin Configuration
SOJ
Top View
I/O
0
INPUT BUFFER
A
0
A
1
A
2
A
3
A
4
A
5
A
6
A
7
A
8
A
9
A
10
I/O
1
ROW DECODER
I/O
2
SENSE AMPS
512K x 8
ARRAY
I/O
3
I/O
4
I/O
5
CE
WE
COLUMN
DECODER
POWER
DOWN
I/O
6
I/O
7
A
0
A
1
A
2
A
3
A
4
CE
I/O
0
I/O
1
V
CC
GND
I/O
2
I/O3
WE
A
5
A
6
A
7
A
8
A
9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
NC
A
18
A
17
A
16
A
15
OE
I/O
7
I/O
6
GND
V
CC
I/O
5
I/O
4
A
14
A
13
A
12
A
11
A
10
NC
A
11
A
12
A
13
A
14
A
15
A
16
A
17
A
18
OE
1049V33鈥?
1049V33鈥?
Selection Guide
1049V33-12
Maximum Access Time (ns)
Maximum Operating Current (mA)
Maximum CMOS Standby
Current (mA)
Com鈥檒/Ind鈥檒
Com鈥檒
L
12
150
8
0.5
1049V33-15
15
140
8
0.5
1049V33-17
17
130
8
0.5
1049V33-20
20
120
8
0.5
1049V33-25
25
110
8
0.5
Shaded areas contain preliminary information.
Cypress Semiconductor Corporation
Document #: 38-05067 Rev. **
鈥?/div>
3901 North First Street
鈥?/div>
San Jose
鈥?/div>
CA 95134
鈥?408-943-2600
Revised July 9, 2001
