鈦?/div>
4
input frequency
鈥?Operation at 2x and 4x input frequency (input as low
as 3.75 MHz)
Zero input-to-output delay
50% duty-cycle outputs
LVTTL outputs drive 50鈩?terminated lines
Operates from a single 3.3V supply
Low operating current
32-pin PLCC package
Jitter < 200 ps peak-to-peak (< 25 ps RMS)
selectable control over system clock functions. These multiple-
output clock drivers provide the system integrator with func-
tions necessary to optimize the timing of high-performance
computer systems. Eight individual drivers, arranged as four
pairs of user-controllable outputs, can each drive terminated
transmission lines with impedances as low as 50鈩?while deliv-
ering minimal and specified output skews and full-swing logic levels
(LVTTL).
Each output can be hardwired to one of nine delay or function
configurations. Delay increments of 0.7 to 1.5 ns are deter-
mined by the operating frequency with outputs able to skew up
to
鹵6
time units from their nominal 鈥渮ero鈥?skew position. The com-
pletely integrated PLL allows external load and transmission
line delay effects to be canceled. When this 鈥渮ero delay鈥?capa-
bility of the LVPSCB is combined with the selectable output
skew functions, the user can create output-to-output delays of
up to
鹵12
time units.
Divide-by-two and divide-by-four output functions are provided
for additional flexibility in designing complex clock systems.
When combined with the internal PLL, these divide functions
allow distribution of a low-frequency clock that can be multi-
plied by two or four at the clock destination. This facility mini-
mizes clock distribution difficulty while allowing maximum sys-
tem clock speed and flexibility.
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Functional Description
The CY7B9911V 3.3V RoboClock+ High-Speed Low-Voltage
Programmable Skew Clock Buffer (LVPSCB) offers user-
Logic Block Diagram
TEST
Pin Configuration
PLCC
3F0
2F1
FS
FILTER
REF
FS
4F0
4F1
4
3F1
4Q0
SELECT
INPUTS
(THREE
LEVEL)
4Q1
V
CCQ
SKEW
3Q0
3Q1
SELECT
2Q0
MATRIX
2Q1
1Q0
1Q1
7B9911V鈥?
3
2
1
5
6
7
8
9
10
11
12
32 31 30
29
28
27
26
TEST
V
CCQ
GND
REF
FB
PHASE
FREQ
DET
VCO AND
TIME UNIT
GENERATOR
2F0
GND
1F1
1F0
V
CCN
1Q0
1Q1
GND
GND
4F0
4F1
3F0
3F1
V
CCN
4Q1
4Q0
GND
GND
CY7B9911V
25
24
23
22
2F0
2F1
13
21
14 15 16 17 18 19 20
3Q1
3Q0
FB
2Q1
2Q0
CCN
CCN
1F0
1F1
V
V
7B9911V鈥?
Cypress Semiconductor Corporation
鈥?/div>
3901 North First Street
鈥?/div>
San Jose
鈥?/div>
CA 95134
鈥?/div>
408-943-2600
December 1, 1999
