Data sheet acquired from Cypress Semiconductor Corporation.
Data sheet modi鏗乪d to remove devices not offered.
CY74FCT16543T
CY74FCT162543T
CY74FCT162H543T
SCCS059B - August 1994 - Revised September 2001
16-Bit Latched Transceivers
Functional Description
The CY74FCT16543T and CY74FCT162543T are 16-bit,
high-speed, low power latched transceivers that are organized as two
independent 8-bit D-type latched transceivers containing two sets of
eight D-type latches with separate Latch Enable (LEAB, LEAB) and
Output Enable (OEAB, OEAB) controls for each set to permit
independent control of inputting and outputting in either direction of
data flow. For data flow from A to B, for example, the A-to-B input
Enable (CEAB) must be LOW in order to enter data from A or to take
data from B as indicated in the truth table. With CAEB LOW, a LOW
signal on the A-to-B Latch Enable (LEAB) makes the A-to-B latches
transparent; a subsequent LOW-to-HIGH transition of the LEAB
signal puts the A latches in the storage mode and their outputs no
longer change with the A inputs. With CEAB and OEAB both LOW,
the three-state B output buffers are active and reflect the data present
at the output of the A latches. Control of data from B to A is similar,
but uses CEAB, LEAB, and OEAB inputs flow-through pinout and
small shrink packaging and in simplifying board design.
This device is fully speci鏗乪d for partial-power-down
applications using I
off
. The I
off
circuitry disables the outputs,
preventing damaging current back鏗俹w through the device
when it is powered down.
The CY74FCT16543T is ideally suited for driving
high-capacitance loads and low-impedance backplanes.
The CY74FCT162543T has 24-mA balanced output drivers
with current limiting resistors in the outputs. This reduces the
need for external terminating resistors and provides for
minimal undershoot and reduced ground bounce. The
CY74FCT162543T is ideal for driving transmission lines.
The CY74FCT162H543T is a 24-mA balanced output part that
has 鈥渂us hold鈥?on the data inputs. The device retains the
input鈥檚 last state whenever the input goes to high impedance.
This eliminates the need for pull-up/down resistors and
prevents 鏗俹ating inputs.
Features
鈥?I
off
supports partial-power-down mode operation
鈥?Edge-rate control circuitry for signi鏗乧antly improved
noise characteristics
鈥?Typical output skew < 250 ps
鈥?ESD > 2000V
鈥?TSSOP (19.6-mil pitch) and SSOP (25-mil pitch)
packages
鈥?Industrial temperature range of
鈭?0藲C
to +85藲C
鈥?V
CC
= 5V
鹵
10%
CY74FCT16543T Features:
鈥?64 mA sink current, 32 mA source current
鈥?Typical V
OLP
(ground bounce) <1.0V at V
CC
= 5V,
T
A
= 25藲C
CY74FCT162543T Features:
鈥?Balanced 24 mA output drivers
鈥?Reduced system switching noise
鈥?Typical V
OLP
(ground bounce) <0.6V at V
CC
= 5V,
T
A
= 25藲C
CY74FCT162H543T Features:
鈥?Bus hold retains last active state
鈥?Eliminates the need for external pull-up or pull-down
resistors
