MediaClock鈩?/div>
Digital TV Clock Generator with VCXO
Features
鈥?Low jitter, high-accuracy outputs
鈥?VCXO with analog adjust
鈥?3.3V operation
Benefits
Meets critical timing requirements in complex system designs
Large 鹵150-ppm range, better linearity
Enables application compatibility
Frequency Table
Part Number
CY24133-1
Outputs
2
Input Frequency Range
27-MHz pullable Crystal per
Cypress Specification
Output Frequency Range
3.072-, 4.096-, 6.144-, 11.2896-, 12.288-MHz-selectable output
frequencies and 27-MHz reference output
Logic Block Diagram
XIN
OSC
XOUT
Q
桅
VCO
P
VCXO
CLKOUT
PLL
Output
Multiplexer
and Dividers
REFCLK
FS0
FS1
FS2
ROM
AVDD
VDD AVSS VSS
VDDL VSSL
Pin Configuration
CY24133-1
16-pin TSSOP
XIN
VDD
AVDD
VCXO
AVSS
VSSL
FS2
FS1
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
XOUT
NC
NC
VSS
REFCLK
VDDL
FS0
CLKOUT
