CAT24WC05R-TE13 Datasheet

  • CAT24WC05R-TE13

  • I2C Serial EEPROM

  • 9頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CAT24WC03/05
2K/4K-Bit Serial EEPROM with Partial Array Write Protection
FEATURES
s
400 kHz I
2
C bus compatible*
s
1.8 to 6.0 volt operation
s
Low power CMOS technology
s
Write protect feature
s
Self-timed write cycle with auto-clear
s
1,000,000 Program/Erase cycles
s
100 Year data retention
s
8-pin DIP, 8-pin SOIC, 8-lead MSOP and 8-pin
TSSOP Package
s
Commercial, industrial and automotive
鈥揟op 1/2 array protected when WP at V
IH
s
16-Byte page write buffer
temperature ranges
DESCRIPTION
The CAT24WC03/05 is a 2K/4K-bit Serial CMOS
EEPROM internally organized as 256/512 words of 8
bits each. Catalyst鈥檚 advanced CMOS technology sub-
stantially reduces device power requirements. The
CAT24WC03/05 features a 16-byte page write buffer.
The device operates via the I
2
C bus serial interface, has
a special write protection feature, and is available in 8-
pin DIP or 8-pin SOIC packages.
PIN CONFIGURATION
DIP Package (P)
A0
A1
A2
VSS
1
2
3
4
8
7
6
5
VCC
WP
SCL
SDA
BLOCK DIAGRAM
EXTERNAL LOAD
SOIC Package (J)
A0
A1
A2
VSS
1
2
3
4
8
7
6
5
VCC
WP
SCL
SDA
DOUT
ACK
VCC
VSS
WORD ADDRESS
BUFFERS
SENSE AMPS
SHIFT REGISTERS
COLUMN
DECODERS
MSOP Package (R)
A0
A1
A2
VSS
1
2
3
4
8
7
6
5
VCC
WP
SCL
SDA
A0
A1
A2
VSS
TSSOP Package (U)
1
2
3
4
8
7
6
5
VCC
WP
SCL
SDA
SDA
START/STOP
LOGIC
XDEC
WP
CONTROL
LOGIC
E
2
PROM
PIN FUNCTIONS
Pin Name
A0, A1, A2
SDA
SCL
WP
V
CC
V
SS
Function
Device Address Inputs
Serial Data/Address
Serial Clock
Write Protect
+1.8V to +6.0V Power Supply
Ground
A0
A1
A2
SLAVE
ADDRESS
COMPARATORS
SCL
STATE COUNTERS
DATA IN STORAGE
HIGH VOLTAGE/
TIMING CONTROL
24WCXX F03
* Catalyst Semiconductor is licensed by Philips Corporation to carry the I
2
C Bus Protocol.
漏 2001 by Catalyst Semiconductor, Inc.
Characteristics subject to change without notice
1
Doc. No. 1005, Rev. A
