Flexible dual output unit
15A maximum per channel
Industry standard footprint
MTBF >2 million hours (Bellcore 332)
Input voltage to ETS300-132-2
Adjustable output voltage
2:1 input range
Undervoltage lockout (UVLO)
UL, VDE and CSA safety approvals
[ 2 YEAR WARRANTY ]
The BXB75 Dual is a high power density DC/DC converter packaged in the
industry standard footprint (2.40 x 2.28 x 0.50 inches). With no minimum load
requirements, either output can supply its maximum current, or both channels can
support any combination of loading to a total of 60/75W of output power. Suitable
for a wide range of applications in nearly any industry, the BXB75 Dual was
designed with communication and distributed power applications in mind.
Aluminum baseplate technology with four threaded inserts makes heatsink
attachment and optimum thermal management easy. The BXB75 Dual series is
approved to IEC950 by UL, CSA and VDE.
SPECIFICATION
OUTPUT SPECIFICATIONS
Voltage adjustability
Set point accuracy
Line regulation
Load regulation
Minimum load
Undershoot
Ripple and noise
5Hz to 20MHz
Temperature coefficient
Transient response
(See Note 2)
Remote sense
INPUT SPECIFICATIONS
Input voltage range
Input current
Input current (max.)
(See Note 4)
All specifications are typical at nominal input, full load at 25擄C unless otherwise stated
EMC CHARACTERISTICS
鹵5.0%
鹵2.0%
GENERAL SPECIFICATIONS
鹵0.25%
Efficiency
鹵0.50%
See table
Input/case
Input/output
Output/case
Fixed
1000VDC
1500VDC
1500VDC
400kHz
VDE0805, EN60950, IEC950
UL1950, CSA C22.2 No. 950
Aluminum baseplate
with plastic case
UL94V-0
127g (4.5 oz)
Bellcore 332
(calculated)
>2,000,000 hours
Isolation voltage
(See Note 13)
Switching frequency
Conducted emissions
(See Note 3)
Bellcore 1089, FCC part 15
EN55022, CISPR22
Level A
Level A
Each output
(See Note 14)
1A
None
Each output
(See Note 1)
100mV pk-pk,
40mV rms max.
鹵0.01%/擄C
Approvals and
standards
Case material
鹵2.0% max. deviation
300碌s recovery
to within 鹵1.0%
None
Material flammability
Weight
MTBF
48Vin nominal
No load
Remote OFF
3.3V/2.5V
5V/3.3V
36 to 75VDC
150mA max.
25mA max.
2.5A max. @ lo max. and
Vin = 0 to 75V
3.5A max. @ lo max. and
Vin = 0 to 75V
20mA pk-pk
Thermal performance
Altitude
Vibration
ENVIRONMENTAL SPECIFICATIONS
Operating case temp. -40擄C to +100擄C
Non-operating
-50擄C to +110擄C
Operating
Non-operating
5Hz to 500Hz
10,000 feet max.
40,000 feet max.
2.4G rms (approx.)
Input reflected ripple
(See Note 6)
Active low remote ON/OFF
Logic compatibility
ON
OFF
Undervoltage lockout
Start-up time
(See Note 8)
(See Note 7)
Ref. to -input CMOS/TTL
1.2VDC max.
3.5VDC min. or open circuit
30V typ.
International Safety Standard Approvals
VDE0805/EN60950/IEC950 File No. 10401-3336-1095
Licence No. 6249
UL1950 File No. E136005
Power up
Remote ON/OFF
10ms, max.
2.5ms max.
CSA C22.2 No. 950 File No. LR41062C
PAGE 1
