Single and dual output
3W Wide Input DC/DC Converters
1
3 Watts in DIL Package
9 models including 3.3VDC output
Wide input ranges 9-18V, 18-36V, 36-75V
EN55022 conducted emissions level A (optional)
Continuous short circuit protection
Operating temperature range -25擄C to +105擄C
Input voltage range to ETS300-132-2
UL, VDE and CSA safety approvals
The BXA3 Series of DC/DC converters is designed to offer the optimum
cost/benefit power solution for a wide variety of applications including public
and private telecommunications, industrial systems and process and test
equipment. The series consists of 9 models with input voltages of 9-18VDC, 18-
36VDC and 36-75VDC, and offers standard output voltages of 3.3V, 5V, 12V and
15V in single and dual output configurations. Continuous short circuit protection,
overvoltage protection, 60mV output ripple and EN55022 level A conducted
noise compliance minimize design-in time, cost and eliminate the need for
external components.
2 YEAR WARRANTY
All specifications are typical at nominal input, full load at 25擄C unless otherwise stated
SPECIFICATIONS
OUTPUT SPECIFICATIONS
Voltage accuracy
Line regulation
Load regulation
Ripple and noise
(5Hz to 20MHz)
LL to HL, all outputs
Full load to no load
+5V output
All others
Temperature coefficient
Over voltage protection
Short circuit protection
INPUT SPECIFICATIONS
Input voltage range
12VDC
24VDC
48VDC
Suffix 鈥?F鈥?(See Note 5)
(See Note 7)
Output remains within
specification
9 to 18VDC
18 to 36VDC
36 to 75VDC
Pi type
Yes
5V/ms
Clamp diode
鹵1.0%
鹵2.5%
鹵2.5%
60mV pk-pk, max.,
15mV rms
100mV pk-pk, max.,
15mV rms
鹵0.02%/擄C, max.
135% Vout
Continuous
automatic recovery
EMC CHARACTERISTICS
Conducted emissions
EN55022, FCC part 15
Suffix 鈥?F鈥?versions
(See Notes 5 and 6)
Level A
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Switching frequency
Approvals and
standards
Case material
Material flammability
Weight
MTBF
MIL-HDBK-217F
Input/output
Variable
See table
500VDC
200kHz to1MHz
VDE0805, EN60950, IEC950
UL1950, CSA C22.2 No. 950
Non-conductive
black plastic
UL94V-0 min.
15g (0.53oz)
800,000 hours
Input filter
Reverse voltage
protection
Max. input rise
and fall time
ENVIRONMENTAL SPECIFICATIONS
Thermal performance
Operating ambient
-25擄C to +105擄C
(See derating curve)
Non-operating amb
-40擄C to +105擄C
Cooling
Free air convection
cooled
Non-condensing
Operating
Non operating
5Hz to 500Hz
5% to 95% RH
10,000 feet max.
40,000 feet max.
2.5G rms (approx.)
Relative humidity
Altitude
Vibration
File Name: BXA3.PDF Rev: 02 Oct 2002
