BSI
FEATURES
Ultra Low Power/Voltage CMOS SRAM
256K x 16 or 512K x 8 bit switchable
DESCRIPTION
BS616UV4020
鈥?Ultra low operation voltage : 1.8 ~ 3.6V
鈥?Ultra low power consumption :
Vcc = 2.0V C-grade: 15mA (Max.) operating current
I-grade : 20mA (Max.) operating current
0.2uA (Typ.) CMOS standby current
Vcc = 3.0V C-grade: 20mA (Max.) operating current
I-grade : 25mA (Max.) operating current
0.25uA (Typ.) CMOS standby current
鈥?High speed access time :
-70
70ns (Max.) at Vcc=2.0V
-10
100ns (Max.) at Vcc=2.0V
鈥utomatic power down when chip is deselected
鈥?Three state outputs and TTL compatible
鈥?Fully static operation
鈥?Data retention supply voltage as low as 1.5V
鈥?Easy expansion with CE1, CE2 and OE options
鈥?I/O Configuration x8/x16 selectable by CIO, LB and UB pin
The BS616UV4020 is a high performance, ultra low power CMOS Static
Random Access Memory organized as 262,144 words by 16 bits or
524,288 bytes by 8 bits selectable by CIO pin and operates from a
wide range of 1.8V to 3.6V supply voltage.
Advanced CMOS technology and circuit techniques provide both high
speed and low power features with a typical CMOS standby current
of 0.2uA and maximum access time of 70/100ns in 2V operation.
Easy memory expansion is provided by active HIGH chip
enable2(CE2), active LOW chip enable1(CE1), active LOW
output enable(OE) and three-state output drivers.
The BS616UV4020 has an automatic power down feature, reducing the
power consumption significantly when chip is deselected.
The BS616UV4020 is available in DICE form and 48-pin BGA type.
PRODUCT FAMILY
PRODUCT FAMILY
BS616UV4020DC
BS616UV4020BC
BS616UV4020DI
BS616UV4020BI
OPERATING
TEMPERATURE
O
O
Vcc RANGE
SPEED
(ns)
Vcc=2V
POWER DISSIPATION
STANDBY
Operating
(I
CCSB1
, Max)
(I
CC
, Max)
PKG TYPE
DICE
BGA-48-0810
DICE
BGA-48-0810
Vcc=2V
Vcc=3V
Vcc=2V
Vcc=3V
Vcc=3V
+0 C to +70 C
-40 C to +85 C
O
O
1.8V ~ 3.6V
1.8V ~ 3.6V
70 / 100
70 / 100
1uA
2uA
1.5uA
3uA
15mA
20mA
20mA
25mA
PIN CONFIGURATION
BLOCK DIAGRAM
A15
A14
A13
A12
A11
A10
A9
A8
A17
A7
A6
Address
Input
Buffer
22
Row
Decoder
2048
Memory Array
2048 x 2048
2048
D0
16(8)
Data
Input
Buffer
16(8)
Column I/O
.
.
.
.
D15
CE1
CE2
WE
OE
UB
LB
CIO
Vdd
Vss
.
.
.
.
Write Driver
16(8)
Sense Amp
128(256)
Column Decoder
16(8)
Data
Output
Buffer
14(16)
Control
Address Input Buffer
A16 A0 A1 A2 A3 A4 A5
(SAE)
