BC327 thru BC328
Vishay Semiconductors
formerly General Semiconductor
Small Signal Transistors (PNP)
TO-226AA (TO-92)
0.181 (4.6)
min. 0.492 (12.5) 0.181 (4.6)
0.142 (3.6)
Features
鈥?PNP Silicon Epitaxial Planar Transistors for switching
and amplifier applications. Especially suitable for
AF-driver stages and low-power output stages.
鈥?These types are also available subdivided into
three groups, -16, -25, and -40, according to their
DC current gain. As complementary types, the NPN
transistors BC327 and BC338 are recommended.
鈥?On special request, these transistors are also
manufactured in the pin configuration TO-18.
Mechanical Data
Case:
TO-92 Plastic Package
Weight:
approx. 0.18g
Packaging Codes/Options:
E6/Bulk 鈥?5K per container, 20K/box
E7/4K per Ammo mag., 20K/box
max.
鈭?/div>
0.022 (0.55)
0.098 (2.5)
Dimensions in inches
and (millimeters)
Bottom
View
Maximum Ratings & Thermal Characteristics
Parameter
Collector-Emitter Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Peak Collector Current
Base Current
Power Dissipation at Tamb = 25擄C
Thermal Resistance Junction to Ambient Air
Junction Temperature
Storage Temperature Range
BC327
BC328
BC327
BC328
Symbol
鈥揤
CES
鈥揤
CEO
鈥揤
EBO
鈥揑
C
鈥揑
CM
鈥揑
B
P
tot
R
螛JA
T
j
T
S
Ratings at 25擄C ambient temperature unless otherwise specified.
Value
50
30
45
25
5
800
1
100
625
(1)
200
(1)
150
鈥?5 to +150
Unit
V
V
V
mA
A
mA
mW
擄C/W
擄C
擄C
Note:
(1) Valid provided that leads are kept at ambient temperature at a distance of 2mm from case.
Document Number 88158
08-May-02
