BAT17W
Vishay Semiconductors
Small Signal Schottky Diode
Features
鈥?Low turn-on voltage Low capacitance
鈥?Ultrafast switching
e3
鈥?Ideal for single or double, UHF balanced
mixer, modulators and phase detectors.
鈥?These diodes are also available in case styles
SOT-23 with type designation BAT17, and
SOD-323 with type designation BAT17WS
鈥?Lead (Pb)-free component
鈥?Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
17431
Mechanical Data
Case:
SOD-123 Plastic case
Weight:
approx. 9.3 mg
Packaging Codes/Options:
GS18 / 10 k per 13" reel (8 mm tape), 10 k/box
GS08 / 3 k per 7" reel (8 mm tape), 15 k/box
Parts Table
Part
BAT17W
Ordering code
BAT17W-GS18 or BAT17W-GS08
L7
Marking
Remarks
Tape and Reel
Absolute Maximum Ratings
T
amb
= 25 擄C, unless otherwise specified
Parameter
Continuous reverse voltage
Forward current
Power dissipation
1)
Test condition
Symbol
V
R
I
F
Value
4
30
150
1)
Unit
V
mA
mW
T
C
= 25 擄C
P
tot
Valid provided that electrodes are kept at ambient temperature
Thermal Characteristics
T
amb
= 25 擄C, unless otherwise specified
Parameter
Thermal resistance junction to
ambient air
Maximum junction temperature
Storage temperature range
1)
Test condition
Symbol
R
thJA
T
j
T
S
Value
500
1)
125
- 65 to + 150
Unit
擄C/W
擄C
擄C
Valid provided that electrodes are kept at ambient temperature
