Features
1) All the audio-switching functions required for SECAM
CANAL -plus decoder integrated onto one chip.
2) Inputs terminated with 65k鈩?resistors.
3) Built-in output buffer.
4) Wide supply voltage range (4.5V to 13.0V).
5) Low total harmonic distortion (0.005% Typ.).
6) Wide dynamic range (3.6Vrms, V
CC
= 12V).
7) Same control logic as for the BA7630S can be used.
鈥?/div>
Absolute maximum ratings
Parameter
Applied voltage
Power dissipation
Operating temperature
Storage temperature
Symbol
V
CC
Pd
Topr
Tstg
Limits
13.5
1100
鈭?/div>
(DIP)
500
鈭?/div>
(SOP)
鈥?25 ~ + 70
鈥?55 ~ + 125
Unit
V
mV
擄C
擄C
鈭?/div>
Reduced by 11mW (DIP) or 5mW (SOP) for each increase in Ta of 1擄C over 25擄C.
