Standard ICs
Dual high slew rate operational
amplifier
BA4560 / BA4560F / BA4560N
The BA4560, BA4560F, and BA4560N are dual operational amplifiers which achieve approximately twice the high
output current of the BA4558, as well as featuring a higher slew rate of 4V /
碌s,
a gain band width of 10MHz, and an
improved frequency characteristic. The following packages are available: 8-pin DIP (BA4560), 8-pin SOP (BA4560F),
and 8-pin SIP (BA4560N).
鈥?/div>
Applications
Active filters
Audio amplifiers
VCOs
Other electronic circuits
鈥?/div>
Featuresoutput short-circuit protection circuit.
1) Built-in
2) Internal phase correction.
3) No latch-up.
4) Wide range of common-mode modes and differential
voltage.
5) High gain and low noise.
鈥?/div>
Block diagram
BA4560 / BA4560F
BA4560N
OUT1 1
8
V
CC
+
1ch
鈥?/div>
+
2ch
鈥?/div>
鈥?IN1 2
鈥?/div>
+ IN1 3
1ch
7
OUT2
+
2ch
+
鈥?/div>
6
鈥?IN2
1
2
3
4
5
6
7
OUT2
8
V
CC
+ IN1
鈥?IN1
+ IN2
OUT1
鈥?IN2
V
EE
V
EE
4
5
+ IN2
1
