Bay Linear
Inspire the Linear Power
N-CHANNEL DMOS FET SWITCH
High Gain Level Shifter
B3520/B3540
Series
Description
The B3520 series consists of enhancement-mode
MOSFETs designed for high speed low-glitch switching
in audio, video, and high-frequency wireless
applications. The CT3520 is optimized as a high speed
driver. With a source feedback resistor it can be uses as
a high speed LED Driver.
The B3520 series uses Bay Linear ULTRA REL DMOS
Process for reliability and robust performance.
These MOSFETs utilize lateral construction to achieve
low capacitance and ultra-fast switching speeds. An
integrated Zener diode provides ESD protection.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Low capacitance 鈥?0.3pF typical
Low threshold 鈥?<1.5V max
Fast switching 鈥?ton<1ns
CMOS and TTL Compatible Input
Application
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
LED Drivers
Level Shifting
Switch Drivers
VHF/UHF Amplifiers
Pin Connection
SOT-143 Package
Lead Code Identification
(top view)
Ordering Information
Package
SOT-143
SOT-143
Part No.
B3520K4 -X.X
B3540K4-XX
Body
Substrate
1
4
Gate
Source
2
3
Drain
Bay Linear, Inc
2418 Armstrong Street, Livermore, CA 94550 Tel: (925) 606-5950, Fax: (925) 940-9556
www.baylinear.com
