ARIZONA MICROTEK, INC.
AZ100EL16VS
ECL/PECL Differential Receiver with Variable Output Swing
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
250ps Propagation Delay
High Bandwidth Output Transitions
75k鈩?Internal Input Pulldown Resistors
Functionally Equivalent to ON
Semiconductor MC100EL16
Variable Output Swing
Available in a 3x3mm MLP Package
PACKAGE AVAILABILITY
PACKAGE
MLP 8
MLP 8 T&R
MLP 8 T&R
SOIC 8
SOIC 8 T&R
SOIC 8 T&R
TSSOP 8
TSSOP 8 T&R
TSSOP 8 T&R
PART NO.
AZ100EL16VSL
AZ100EL16VSLR1
AZ100EL16VSLR2
AZ100EL16VSD
AZ100EL16VSDR1
AZ100EL16VSDR2
AZ100EL16VST
AZ100EL16VSTR1
AZ100EL16VSTR2
MARKING
AZM16P
AZM16P
AZM16P
AZM100EL16VS
AZM100EL16VS
AZM100EL16VS
AZH16VS
AZH16VS
AZH16VS
DESCRIPTION
The AZ100EL16VS is a differential receiver with variable output swing. The EL16VS has functionality and
output transition times similar to the EL16, with an input that controls the amplitude of the Q/Q outputs. Maximum
爐
swing is achieved by leaving the V
CTRL
pin open or tied to V
EE
.
The operational range of the EL16VS control input, V
CTRL
, is from V
BB
(full swing) to V
CC
(min. swing).
Simple control of the output swing can be obtained by a variable resistor between the V
BB
and V
CC
pins, with the
wiper driving V
CTRL
. Typical application circuits and results are described in this Data Sheet.
The EL16VS provides a V
BB
output for single-ended use or a DC bias reference for AC coupling to the device.
For single-ended input applications, the V
BB
reference should be connected to one side of the D/D differential input
爐
pair. The input signal is then fed to the other D/D input. The V
BB
pin can support 1.0mA sink/source current.
爐
When used, the V
BB
pin should be bypassed to ground via a 0.01碌F capacitor.
Under open input conditions (pulled to V
EE
) internal input clamps will force the Q output LOW.
NOTE: Specifications in ECL/PECL tables are valid when thermal equilibrium is established.
1630 S. STAPLEY DR., SUITE 125
鈥?/div>
MESA, ARIZONA 85204
鈥?/div>
USA
鈥?/div>
(480) 962-5881
鈥?/div>
FAX (480) 890-2541
www.azmicrotek.com
