Low Noise Ampli鏗乪r, 8.5 dB Gain
10 - 400 MHz
AM-/AMC-/AMS-181
V2.00
Features
q
q
q
q
TO-8-1
DC IN
RF OUT
GND
0.220 MIN
(5.6)
RF IN
0.300 TYP
(7.8)
鹵0.005
DIA
(0.46
鹵0.13)
4 PINS
0.450
(11.4)
0.50 DIA
(12.7
鹵0.5)
0.150 TYP
(3.8)
1.5 dB Typical Midband Noise Figure
+31 dBm Typical Midband Intercept
Ideal for Broadband IF Applications
Fully Hermetic Package (AMS-181)
Guaranteed Speci鏗乧ations*
0.220 MAX
(5.6)
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵0.010 (.xx = 鹵 0.25)
.xx = 鹵0.02 (.x = 鹵0.5)
Weight (Approx.): 0.10 Ounces 2.8 Grams
C-32
Operating Characteristics
*All speci鏗乧ations apply when operated at +15 VDC with 50 ohm
source and load impedance. This product contains elements
protected by United States Patent Number 3,891,934.
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵0.010 (.xx = 鹵 0.25)
.xx = 鹵0.02 (.x = 鹵0.5)
WEIGHT (APPROX.): 1.62 OUNCES 46 GRAMS
Ordering Information
Model No.
AM-181* Pin
AMC-181 SMA
AMS-181 PIN
Package
Pin
Connectorized
Surface Mount
*Mounting kit part number AU0007 required for PCB applications.
Speci鏗乧ations Subject to Change Without Notice.
