AVR 鈥?High-performance and Low-power RISC Architecture
鈥?118 Powerful Instructions 鈥?Most Single Clock Cycle Execution
鈥?32 x 8 General-purpose Working Registers
鈥?Up to 10 MIPS Throughput at 10 MHz
Data and Nonvolatile Program Memory
鈥?2K Bytes of In-System Programmable Flash
Endurance: 1,000 Write/Erase Cycles
鈥?128 Bytes Internal RAM
鈥?128 Bytes of In-System Programmable EEPROM
Endurance: 100,000 Write/Erase Cycles
鈥?Programming Lock for Flash Program and EEPROM Data Security
Peripheral Features
鈥?One 8-bit Timer/Counter with Separate Prescaler
鈥?Programmable Watchdog Timer with On-chip Oscillator
鈥?SPI Serial Interface for In-System Programming
Special Microcontroller Features
鈥?Low-power Idle and Power-down Modes
鈥?External and Internal Interrupt Sources
鈥?Power-on Reset Circuit
鈥?Selectable On-chip RC Oscillator
Specifications
鈥?Low-power, High-speed CMOS Process Technology
鈥?Fully Static Operation
Power Consumption at 4 MHz, 3V, 25擄C
鈥?Active: 2.4 mA
鈥?Idle Mode: 0.5 mA
鈥?Power-down Mode: <1 碌A
I/O and Packages
鈥?Three Programmable I/O Lines (AT90S/LS2323)
鈥?Five Programmable I/O Lines (AT90S/LS2343)
鈥?8-pin PDIP and SOIC
Operating Voltages
鈥?4.0 - 6.0V (AT90S2323/AT90S2343)
鈥?2.7 - 6.0V (AT90LS2323/AT90LS2343)
Speed Grades
鈥?0 - 10 MHz (AT90S2323/AT90S2343)
鈥?0 - 4 MHz (AT90LS2323/AT90LS2343)
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
8-bit
Microcontroller
with 2K Bytes of
In-System
Programmable
Flash
AT90S2323
AT90LS2323
AT90S2343
AT90LS2343
鈥?/div>
鈥?/div>
鈥?/div>
Description
The AT90S/LS2323 and AT90S/LS2343 are low-power, CMOS, 8-bit microcontrollers
based on the AVR RISC architecture. By executing powerful instructions in a single
clock cycle, the AT90S2323/2343 achieves throughputs approaching 1 MIPS per MHz
allowing the system designer to optimize power consumption versus processing
speed.
(continued)
Pin Configuration
PDIP/SOIC
RESET
(CLOCK) PB3
PB4
GND
1
2
3
4
8
7
6
5
VCC
PB2 (SCK/T0)
PB1 (MISO/INT0)
PB0 (MOSI)
RESET
XTAL1
XTAL2
GND
1
2
3
4
8
7
6
5
VCC
PB2 (SCK/T0)
PB1 (MISO/INT0)
PB0 (MOSI)
Rev. 1004CS鈥?0/00
AT90S/LS2343
AT90S/LS2323
Note: This is a summary document. A complete document is
available on our web site at
www.atmel.com.
1
