AT24C16SC-09ET Datasheet

  • AT24C16SC-09ET

  • Two-wire Serial EEPROM Smart Card Modules

  • 14頁

  • ATMEL   ATMEL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features
鈥?/div>
Low-voltage and Standard-voltage Operation, VCC = 2.7V鈥?.5V
鈥?/div>
Internally Organized 128 x 8 (1K), 256 x 8 (2K), 512 x 8 (4K),
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
1024 x 8 (8K), or 2048 x 8 (16K)
Two-wire Serial Interface
Schmitt Trigger, Filtered Inputs for Noise Suppression
Bidirectional Data Transfer Protocol
400 kHz Compatibility
8-byte Page (1K, 2K), 16-byte Page (4K, 8K, 16K) Write Modes
Partial Page Writes Allowed
Self-timed Write Cycle (5 ms max)
High Reliability
鈥?Endurance: One Million Write Cycles
鈥?Data Retention: 100 Years
鈥?ESD Protection: >3000V
Description
The AT24C01A/02SC/04SC/08SC/16SC provide 1024/2048/4096/8192/16384 bits of
serial, electrically-erasable, and programmable read-only memory (EEPROM) orga-
nized as 128/256/512/1024/2048 words of 8 bits each. The devices are optimized for
use in smart card applications where low-power and low-voltage operation may be
essential. The devices are available in several standard ISO 7816 smart card modules
(see
Ordering Information,
pages 12鈥?3). All devices are functionally equivalent to
Atmel serial EEPROM products offered in standard IC packages (PDIP, SOIC, TSSOP,
MAP), with the exception of the slave address and write protect functions, which are
not required for smart card applications.
Table 1.
Pin Configuration
Pad Name
VCC
GND
SCL
SDA
NC
Description
Power Supply Voltage
Ground
Serial Clock Input
Serial Data Input/Output
No Connect
ISO Module Contact
C1
C5
C3
C7
C2, C4, C6, C8
Two-wire Serial
EEPROM Smart
Card Modules
1K (128 x 8)
2K (256 x 8)
4K (512 x 8)
8K (1024 x 8)
16K (2048 x 8)
AT24C01ASC
AT24C02SC
AT24C04SC
AT24C08SC
AT24C16SC
Figure 1.
Card Module Contact
VCC
NC
1610B鈥揝EEPR鈥?4/04
1
