AS4041BN-3 Datasheet

  • AS4041BN-3

  • Analog IC

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

AS4041
Precision Micropower 1.24V Shunt Voltage Reference
FEATURES
APPLICATIONS
鈥?/div>
Low temperature coefficient 50 ppm/擄C
鈥?/div>
Operating current range 100碌A(chǔ) to 15 mA
鈥?/div>
Low power, 250 mW @ I
IN
=100 mA
鈥?/div>
Two terminal "Zener" operation
鈥?/div>
Small package: SOT - 23, TO-92, and SO-8
鈥?/div>
Fixed reverse breakdown voltage 2.5 Volt
鈥?/div>
No output capacitance required
鈥?/div>
Output voltage tolerance
鹵
0.5%
鈥?/div>
Constant Current Source
鈥?/div>
Digital Voltmeter
鈥?/div>
Power Supply Monitor
鈥?/div>
Precision Regulators
鈥?/div>
Battery-Powered Equipment
鈥?/div>
Instrumentation
鈥?/div>
Automotive Electronics
鈥?/div>
Data Acquisition Systems
鈥?/div>
Energy Management
PRODUCT DESCRIPTION
The AS4041 is a two-terminal, temperature compensated, band-gap voltage reference, which provides a fixed 1.24V output for input
currents between 500
碌A(chǔ)
to 5mA. The bandgap voltage (1.24V) is independently laser trimmed from the output voltage to achieve a
very low tempco, then the output voltage is laser trimmed to 1.24 volts. This trimming technique and the low tempco (A grade 50
ppm/
擄C)
thin film resistor process gives a very stable device over the full temperature range. The AS4041 is available in the sub-
miniature (3mm
脳
1.3mm) SOT-23, SO-8 surface mount package, or TO-92 package. The operating temperature is -40擄C to 85擄C.
The ALPHA Semiconductor AS4041 advanced design eliminates the need for an external stabilized capacitor while insuring stability
with any capacitive load, making them easy to use.
ORDERING INFORMATION
Part Number
Package Type
Y=
Tempco
A=100ppm/擄C
B=150ppm/擄C
X=
Output Accuracy
2=1%
3=2%
AS4041YN-X
TO-92
AS4041YS-X
SO-8
AS4041YM-X
SOT-23
1. For lower Tempco, consult factory
PIN CONNECTIONS
8-Pin Surface Mount (S)
N/C
N/C
N/C
-
1
2
3
4
8
7
6
5
+
N/C
N/C
N/C
-
3
SOT-23-3 (M)
2
1
TO-92 (N)
1
2
3
+
Bottom View
Top View
Top View
Rev. 10/11/00
