AQ-F SOLID STATE RELAY
AQ-F
RELAYS
27.4
1.079
21
.827
UL File No.: E43149
CSA File No.: LR26550
鈥?Suitable for high-capacity and high-frequency switching
鈥?Same size, same terminal arrangement as HC relay
Sockets for HC relays are applicable
鈥?Two load types available: DC output type (2 A, 3 A)
AC output type (2 A, 3 A)
鈥?Wide range of input voltage: 3 V to 28 V
35.2
1.386
mm
inch
TYPES
Type
AC output
Zero-cross 2 A
Zero-cross 3 A
2A
3A
Part No.
AQF2A2-ZT3/28VDC
AQF3A2-ZT3/28VDC
AQF2AD1-3/28VDC
AQF3AD1-3/28VDC
DC output
Drive for small-sized motor, heater, solenoid and
electromagnetic valves.
鈥?NC machine
鈥?Printing machine
鈥?Machine tool
鈥?Robot for industrial use
鈥?Wrapping and packing machine
APPLICATIONS
SPECIFICATIONS
Ratings
(at 20擄C
68擄F,
Input voltage ripple: 1% or less)
AC output
DC output
AQF2A2-ZT3/28VDC AQF3A2-ZT3/28VDC AQF2AD1-3/28VDC AQF3AD1-3/28VDC
Item
Input voltage
3 to 28 V DC
Input
Input impedance
Approx. 1.6 k鈩?(3 to 28 V DC)
side
Drop-out voltage, min.
0.8 V DC
Max. load current
Load voltage
Non-repetitive surge
Load current
side
Max. 鈥淥FF-state鈥?/div>
leakage current
Max. 鈥淥N-state鈥?/div>
voltage drop
Min. load curent
2A
75 to 250 V AC
80 A
5 mA
1.6 V
50 mA
5 mA
5A
1 mA
3A
2A
3 to 60 V DC
6A
AC: In one cycle at 60 Hz
DC: 1 s
AC: at 60 Hz 200 V
DC: at 60 V
at max. carrying current
3A
Type
Remarks
See 鈥淒ATA 1鈥?on the
following page
Characteristics
(at 20擄C
68擄F,
Input voltage ripple: 1% or less)
Type
Item
Operate time max.
Release time, max.
Insulation resistance, min.
Breakdown voltage
Functional
Vibration
resistance
Destructive
Functional
Shock
resistance
Destructive
Ambient temperature
Storage temperature
Operational method
AC output
DC output
AQF2A2-ZT3/28 VDC AQF3A2-ZT3/28VDC AQF2AD1-3/28VDC AQF3AD1-3/28VDC
0.5 ms
(1/2 cycle of voltage sine wave) + 1 ms
(1/2 cycle of voltage sine wave) + 1 ms
2 ms
100 M鈩?between input and output
2,000 Vrms between input and output
10 to 55 Hz double amplitude of 3 mm
10 to 55 Hz double amplitude of 3 mm
Min. 980 m/s
2
{100 G}
Min. 980 m/s
2
{100 G}
鈥?0擄C to +80擄C
鈥?2擄F to +176擄F
鈥?0擄C to +100擄C
鈥?2擄F to +212擄F
Zero-cross (Turn-ON and Turn-OFF)
鈥?/div>
Remarks
Initiail at 500 V DC
Initial for 1 min.
10 min. for X, Y, Z axes
1 hour for X, Y, Z axes
4 times each for X, Y, Z axes
5 times each for X, Y, Z axes
1
2
3
4
