FEATURES
Enhanced Replacement for LF441 and TL061
DC Performance:
200 A max Quiescent Current
10 pA max Bias Current, Warmed Up (AD548C)
250 V max Offset Voltage (AD548C)
2 V/ C max Drift (AD548C)
2 V p-p Noise, 0.1 Hz to 10 Hz
AC Performance:
1.8 V/ s Slew Rate
1 MHz Unity Gain Bandwidth
Available in Plastic and Hermetic Metal Can Packages
and in Chip Form
Available in Tape and Reel in Accordance with
EIA-481A Standard
MIL-STD-883B Parts Available
Dual Version Available: AD648
Surface-Mount (SOIC) Package Available
PRODUCT DESCRIPTION
Precision, Low Power
BiFET Op Amp
AD548
CONNECTION DIAGRAMS
Plastic Mini-DIP (N) Package
and
SOIC (R)Package
OFFSET NULL 1
INVERTING 2
INPUT
NONINVERTING 3
INPUT
V鈥?4
8 NC
7 V+
6 OUTPUT
AD548
TOP VIEW
5 OFFSET
NULL
NOTE: PIN 4 CONNECTED TO CASE
NC = NO CONNECT
10k
1
5
4
鈥?5V
The AD548 is a low power, precision monolithic operational
amplifier. It offers both low bias current (10 pA max, warmed
up) and low quiescent current (200
碌A
max) and is fabricated
with ion-implanted FET and laser wafer trimming technologies.
Input bias current is guaranteed over the AD548鈥檚 entire
common-mode voltage range.
The economical J grade has a maximum guaranteed input offset
voltage of less than 2 mV and an input offset voltage drift of less
than 20
碌V/擄C.
This level of dc precision is achieved utilizing
Analog鈥檚 laser wafer drift trimming process. The combination of
low quiescent current and low offset voltage drift minimizes
changes in input offset voltage due to self-heating effects.
The AD548 is recommended for any dual supply op amp applica-
tion requiring low power and excellent dc and ac performance.
In applications such as battery-powered, precision instrument
front ends and CMOS DAC buffers, the AD548鈥檚 excellent com-
bination of low input offset voltage and drift, low bias current,
and low 1/f noise reduces output errors. High common-mode
rejection (82 dB, min on the 鈥淏鈥?grade) and high open-loop
gain ensures better than 12-bit linearity in high impedance,
buffer applications.
The AD548 is pinned out in a standard op amp configuration
and is available in three performance grades. The AD548J and
AD548K are rated over the commercial temperature range of
0擄C to 70擄C. The AD548B is rated over the industrial tempera-
ture range of 鈥?0擄C to +85擄C.
The AD548 is available in an 8-lead plastic mini-DIP and
surface-mount (SOIC) packages.
REV. C
Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties that
may result from its use. No license is granted by implication or otherwise
under any patent or patent rights of Analog Devices.
V
OS
TRIM
TOP VIEW
PRODUCT HIGHLIGHTS
1. A combination of low supply current, excellent dc and ac
performance and low drift makes the AD548 the ideal op
amp for high performance, low power applications.
2. The AD548 is pin compatible with industry standard op
amps such as the LF441, TL061, and AD542, enabling
designers to improve performance while achieving a reduction
in power dissipation of up to 85%.
3. Guaranteed low input offset voltage (2 mV max) and drift
(20
碌V/擄C
max) for the AD548J are achieved utilizing
Analog Devices鈥?laser drift trimming technology, eliminating
the need for external trimming.
4. Analog Devices specifies each device in the warmed-up
condition, insuring that the device will meet its published
specifications in actual use.
5. A dual version, the AD648, is also available.
6. Enhanced replacement for LF441 and TL061.
