AUTOMOTIVE LOW PROFILE
MICRO-ISO/MICRO-280
RELAY
FEATURES
鈥?Low pro鏗乴e:
22.5 mm(L)脳15 mm(W)脳15.7 mm(H)
.886 inch(L)脳.591 inch(W)脳.618 inch(H)
鈥?Low temperature rise
Terminal temperature has been reduced
compared with using our conventional
product
鈥?Low sound pressure level
Noise level has been reduced
approx.10dB compared with using our
conventional product.
鈥?Wide line-up
Micro ISO/Micro 280 terminal types and
resistor and diode inside type, PCB
terminal type (Micro 280 only).
鈥?Plastic sealed type
Plastically sealed for automatic cleaning.
CV-RELAYS
Micro ISO 1c type
Micro ISO 1a type
Micro 280 plug-in type Micro 280 PCB type
SPECIFICATIONS
Contact
Arrangement
Contact material
Initial contact resistance,
max. (By voltage drop 6 V
DC 1 A)
Initial contact voltage drop,
max.
Nominal
switching
capacity
Rating
Max. carrying
current
(14 V DC,
at 85擄C
185擄F)
Mechanical
(at 120 cpm)
1 Form A
Silver alloy
50m鈩?/div>
N.O.: 0.2 V
(at 20 A switching)
N.C.: 0.5 V
(at 10 A switching)
N.O.: 20 A 14 V DC
N.C.: 10 A 14 V DC
N.O.: 20 A
N.C.: 10 A
Vibration resistance
Min. 10
6
Min. 10
5
*
1
Destructive *
8
Conditions in case of
Ambient
operation, transport and
temp*
10
storage *
9
(Not freezing and condensing
Humidity
at low temperature)
Unit weight
Initial
breakdown
voltage *
3
Between open contacts
Between contacts and coil
1 Form C
Characteristics
Max. operating speed
(at nominal switching capacity)
Initial insulation resistance *
2
15cpm
Min. 20M鈩?/div>
(at 500 V DC)
500 Vrms for 1min.
500 Vrms for 1min.
Max. 10ms
Max. 10ms
Min. 100 m/s
2
{10 G}
Min. 1,000 m/s
2
{100 G}
10 to 100 Hz,
Min.44.1 m/s
2
{4.5 G}
10 to 500 Hz,
Min.44.1 m/s
2
{4.5 G}
鈥?0 to +85擄C
鈥?0 to +185擄F
25 to 85% R.H.
Approx. 15.0g
.53 oz
N.O.: 0.2 V
(at 20 A switching)
N.O.: 20 A 14 V DC
Operate time *
4
(at nominal voltage) (at 20擄C
68擄F)
Release time (without diode) *
4
(at nominal voltage) (at 20擄C
68擄F)
Shock resistance
Functional *
5
Destructive *
6
Functional *
7
N.O.: 20 A
Expected
life (min.
operation) Electrical
(at rated load)
Remarks
*
*
1
*
2
*
3
*
4
*
5
*
6
*
7
*
8
Speci鏗乧ations will vary with foreign standards certi鏗乧ation ratings.
At nominal switching capacity, operating frequency: 2s ON, 2s OFF
Measurement at same location as 鈥淚nitial breakdown voltage鈥?section.
Detection current: 10mA
Excluding contact bounce time.
Half-wave pulse of sine wave: 11 ms; detection time: 10
碌s
Half-wave pulse of sine wave: 6 ms
Detection time: 10
碌s
Time of vibration for each direction;
X, Y, Z direction: 4 hours
Y
X
Z
*
9
Refer to 5. Usage, transport and storage condition mentioned in NOTES
*
10
Ambient temperature 125擄C
257擄F
type is also available. Please contact us for
details.
TYPICAL APPLICATIONS
Automotive system
Condenser fan, Wiper, Defogger, Magnet clutch, Radiator fan,
Foglamp, Auto cruise control, Horn, Heater, Air Compressor
1
