MIL-STD-1553B Remote Terminal, BUS Controller,
or Passive Monitor Hybrid with Status Word Control
Dual Low Power Monolithic BUS Tranceivers
Features
鈥?Dual Low Power Monolithic Bus Tranceivers
鈥?Performs the Complete Dual-Redundant Remote Terminal, Bus Controller Protocol
and Passive Monitor Functions of MIL-STD-1553B
鈥?Automated Self-Test Functions
鈥?Allows Setting of the Message Error Bit on Illegal Commands
鈥?Provides programmable control over Terminal Flag and Subsystem Flag Status Bits
鈥?MIL-PRF-38534 Compliant Circuits Available
鈥?250 mw Typical Power Consumption
鈥?Small Size
鈥?Available in Ceramic Plug-in Package Configuration
CIRCUIT TECHNOLOGY
鈥?5V DC Operation
www.aeroflex.com
鈥?Full Military (-55擄C to +125擄C) Temperature Range
鈥?DESC SMD# Pending
1
ACT3492 Series
General Description
The ACT3492 Series is a monolithic implementation of the MIL-STD-1553B Bus Controller, Remote
Terminal and Passive Monitor functions including dual low power Bus tranceivers. All protocol functions
of MIL-STD-1553B are incorporated and a number of options are included to improve flexibility. These
features include programming of the status word, illegalizing specific commands and an independent loop
back self-test which is initiated by the subsystem. This unit is directly compatible with all microprocessor
interfaces such as the CT1611 and CT1800 produced by Aeroflex Incorporated.
Block Diagram (With Transformers)
Encoder
Interface
Unit
Sub Address
&
Word Count
Outputs
ASIC
Decoder
"O"
Driver
Select
&
Enable
Decoder
"1"
BUS "0"
T/R
Hybrid
Status
Word
Control
Program
Inputs
Discrete
Outputs
ASIC
BUS "1"
T/R
Hybrid
Internal
Highway
Control
Control
Inputs
Terminal
Address
Inputs
ASIC
ACT3492
eroflex Circuit T
echnology
鈥?Data Bus Modules For The Future 漏 SCD3492 REV B 6/26/01
