2.32233E+11 Datasheet

  • 2.32233E+11

  • WIDERSTAND DRAHT SILIKON 4R7 3W E12

  • 22頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Philips Components
Product speci鏗乧ation
Cemented wirewound resistors
FEATURES
鈥?/div>
High power dissipation in
small volume
鈥?/div>
High pulse load handling
capabilities.
APPLICATIONS
鈥?/div>
Ballast switching
鈥?/div>
Shunt in small electric motors
鈥?/div>
Power supplies.
DESCRIPTION
AC01/03/04/05/07/10/15/20
The resistor is coated with a green
silicon cement which is not resistant
to aggressive fluxes. The coating is
non-flammable, will not drip even at
high overloads and is resistant to
most commonly used cleaning
solvents, in accordance with
鈥淢IL-STD-202E鈥?/div>
and
鈥淚EC 60068-2-45鈥?
The resistor element is a resistive
wire which is wound in a single layer
on a ceramic rod. Metal caps are
pressed over the ends of the rod.
The ends of the resistance wire and
the leads are connected to the caps
by welding. Tinned copper-clad iron
leads with poor heat conductivity are
employed permitting the use of
relatively short leads to obtain stable
mounting without overheating the
solder joint.
QUICK REFERENCE DATA
VALUE
DESCRIPTION
AC01
Resistance range
0.1
鈩?/div>
to
2 k鈩?/div>
AC03
0.1
鈩?/div>
to
4.7 k鈩?/div>
AC04
0.1
鈩?/div>
to
6.8 k鈩?/div>
AC05
0.1
鈩?/div>
to
8.2 k鈩?/div>
AC07
0.1
鈩?/div>
to
15 k鈩?/div>
AC10
0.68
鈩?/div>
to
27 k鈩?/div>
AC15
0.82
鈩?/div>
to
39 k鈩?/div>
AC20
1.2
鈩?/div>
to
56 k鈩?/div>
Resistance tolerance
Maximum permissible body temperature
Rated dissipation at T
amb
= 40
擄C
Rated dissipation at T
amb
= 70
擄C
Climatic category (IEC 60068)
Basic speci鏗乧ation
Stability after:
load, 1000 hours
climatic tests
short time overload
1W
0.9 W
3W
2.5 W
4W
3.5 W
鹵5%;
E24 series
350
擄C
5W
4.7 W
7W
5.8 W
10 W
8.4 W
15 W
12.5 W
20 W
16 W
40/200/56
IEC 60115-1
鈭哛/R
max.:
鹵5%
+ 0.1
鈩?/div>
鈭哛/R
max.:
鹵1%
+ 0.05
鈩?/div>
鈭哛/R
max.:
鹵2%
+ 0.1
鈩?/div>
1998 Nov 18
2
