Data Sheet

2W STEREO AUDIO POWER AMPLIFIER WITH SHUTDOWN

General Description

The AA4003 is a Class AB stereo Audio Power Ampli-

fier which can deliver 2.0W into 4惟 speakers with lim-

itation of THD+N less than 1%. The chip is designed

specially for Portable DVD player, Portable Media

Player, LCD monitor and Digital Photo Frame applica-

tions.

AA4003 is available in package of SOIC-16 and

TSSOP-20 (EDP).

AA4003

Features

路

Output Power,

BTL: 2.0W/CH (4惟, THD+N

鈮?/div>

1%)

SE: 160mW/CH (16惟, THD+N

鈮?/div>

1%)

Supply Voltage Range: 2.7V to 5.5V

External Feedback Loop for Flexible Gain Set-up

Low Power Consumption at Shutdown Mode

0.7渭A Typical

SE, BTL Mode Switchable

Optimized Click/POP Noise Suppression

Thermal Shutdown Protection

路

Applications

路

Portable DVD Player

Portable Media Player

LCD Monitor

Digital Photo Frame

SOIC-16

TSSOP-20 (EDP)

Figure 1. Packages Type of AA4003

Oct. 2007 Rev. 1. 1

BCD Semiconductor Manufacturing Limited
