UL file E44211; CSA file LR 85091
CONTACTS
Arrangement
Ratings
SPDT (1 Form C)
SPST (1 Form A)
Resistive load:
Max. switched power: 300 W or 2500 VA
Max. switched current: 10 A
Max. switched voltage: 150* VDC or 380 VAC
UL Rating:
10 A at 30 VDC resistive
10 A at 250 VAC general use
1
/
4
HP 120 VAC
1
/
2
HP 250 VAC
B 300 pilot duty
Q 300 pilot duty
*
Note: If switching voltage is greater than 30 VDC, special
precautions must be taken. Please contact the factory.
GENERAL DATA
Life Expectancy
Mechanical
Electrical
Operate Time (typical)
Release Time (typical)
Minimum operations
10 million
1 X 10
5
at 10 A 240 VAC Res.
10 ms at nominal coil voltage
5 ms at nominal coil voltage
(with no coil suppression)
Dielectric Strength
4000 Vrms coil to contact
(at sea level for 1 min.)
1000 Vrms between open contacts
Insulation
Resistance
Dropout
Ambient Temperature
Operating
Storage
Vibration
1000 megohms min. at 20擄C, 500 VDC,
50% RH
Greater than 10% of nominal coil voltage
At nominal coil voltage
-40擄C (-40擄F) to 70擄C (158擄F)
-40擄C (-40擄F) to 110擄C (230擄F)
0.062" DA at 10鈥?5 Hz
20 g
P.B.T. polyester
Tinned copper alloy, P.C.
270擄C (518擄F)
5 seconds
80擄C (176擄F)
30 seconds
14 grams
Material
Resistance
Silver cadmium oxide
< 30 milliohms initially
(at rated current, voltage drop method)
COIL
Power
At Pickup Voltage
(typical)
Max. Continuous
Dissipation
Temperature Rise
Temperature
100 mW
1.5 W at 20擄C (68擄F) ambient
1.2 W at 40擄C (104擄F) ambient
20擄C (36擄F) at nominal coil voltage
Max. 110擄C (230擄F)
Shock
Enclosure
Terminals
Max. Solder Temp.
Max. Solder Time
Max. Solvent Temp.
Max. Immersion Time
NOTES
1. All values at 20擄C (68擄F).
2. Relay may pull in with less than 鈥淢ust Operate鈥?value.
3. Specifications subject to change without notice.
Weight
2/28/01W
