79102ST-0
BENEFITS
Bel鈥檚 series of embedded PowerPacket modules are the first members of the Single Inline Module 鈥?Power Line Enabled
(SIMPLE) family. These modules are specifically designed to allow future Intellon ICs to be used without board redesign. As
new baseband/AFE ICs are introduced by Intellon, pin and function compatible SIMPLE modules can be used to provide
improved functionality and/or reduced cost without requiring any redesign of products using SIMPLE modules.
Based on the industry leading Intellon single-chip PowerPacket transceiver, these modules integrate most of the components
required in a HomePlug solution on a tiny single in-line package. This package can be easily connected into any existing
embedded system via the proprietary SIMPLE PowerBus鈩?header instantly adding HomePlug functionality with virtually no
PCB space and without the hassle of a system redesign.
Each module integrates the chip, crystal, EEPROM, discrete filters, TX/RX power amplifiers and regulators into one single
device. The only external components required are the PLC coupler and transient protection on the AC side of the main
power supply. The host interface for any of the modules can be configured to be MII PHY, GPSI PHY or MII Host/DTE.
The modules are truly the industry鈥檚 most integrated and cost effective way of adding HomePlug 1.0 functionality to any
embedded networking or consumer electronics product.
In Partnership with
漏2003 Bel Fuse Inc. Specifications subject to change without notice. 12.10.03
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
